(G9B80) K-2 Carbide, 2Flute Rib Processing End Mill

  • $47.85INC GST $43.50 EX GST
(G9B80) K-2 Carbide, 2Flute Rib Processing End Mill
(G9B80) K-2 Carbide, 2Flute Rib Processing End Mill

(G9B80) K-2 Carbide, 2Flute Rib Processing End Mill

  • $47.85INC GST $43.50 EX GST

Code: G9B80004

P M K
Mill Diameter (mm)
Loading stock…
Buy Local
Minimum order: $200.00
$200.00 to go
Spend $200.00 or more to enable checkout.
South Korea Made in South Korea
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

SKUMill Diameter (mm)Overall length (mm)Shank dia. (mm)Length of cut (mm)Length below shank (mm)Neck dia. (mm)Stock Price Qty Add
G9B800040.450.04.00.72.00.37 5 days $43.50
G9B800050.550.04.00.752.00.45 In stock $39.80
G9B800060.650.04.00.92.00.55 5 days $39.80
G9B800070.750.04.01.14.00.65 5 days $36.10
G9B800080.850.04.01.24.00.75 5 days $36.10
G9B800090.950.04.01.46.00.85 5 days $36.10
G9B80010150.04.01.56.00.95 Low stock $34.20
G9B800121.250.04.01.86.01.15 5 days $32.20
G9B800151.550.04.02.36.01.45 5 days $32.20
G9B80020250.04.03.06.01.95 5 days $45.20
G9B809312.550.04.03.712.02.4 5 days $45.20
G9B80030350.06.04.58.02.85 5 days $67.80
G9B80040450.06.06.012.03.85 5 days $67.80

Add (G9B80) K-2 Carbide, 2Flute Rib Processing End Mill to comparison

View Comparison
  • Overview
  • Specifications
  • Specifications
  • Operation
  • Work Material
  • Speeds & Feeds
  • Reviews
Product Description

The G9B80 series K2 coated carbide milling cutters feature a long neck for deep pocket milling. K2 carbide range from global market leaders YG-1 are the number 1 best selling tool for general purpose milling. Ideal for general milling steel <45HRc, stainless steel, cast iron, copper & aluminium.

  • Long neck for deep pocket milling
  • Special K2 coating for longer tool life, high heat and wear resistance
  • Dry cutting on steel can increase tool life up to 40%
  • Also suitable for general milling of steel, stainless steel, cast iron & non-ferrous
  • Consistent and reliable performance in general machining conditions
  • Made from high-quality micrograin carbide.
  • Manufactured by global market leader YG-1
Product Data
Workpiece Material P M K
Cutting Shape Square
Hardened Steels(HRc40~45) Great
Helix Angle Square 30
No. Flutes 2
Operation Die Sinking, Facing, Side Milling, Slotting, Small Part
Shank Type Plain YG-1 Standard
Surface Treatment Titanium Aluminium Nitride Coating
Tool Material Carbide
Flutes 2
Helix Angle 30°
Cutting Edge Shape
SQUARE
Size Min D0.4
Size Max D4.0
Length

RIB PROCESSING
Coating TiAIN
EDP No. Mill Diameter ShankDia Length of Cut Length Below Shank Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9B80005 0.5 4 0.75 2 50 0~-0.030 h5 2 G9B80005 0.5 4 0.75 2 50 0~-0.030 h5 2 G9B80007 0.7 4 1.1 4 50 0~-0.030 h5 2 G9B80007 0.7 4 1.1 4 50 0~-0.030 h5 2 G9B80009 0.9 4 1.4 8 50 0~-0.030 h5 2 G9B80009 0.9 4 1.4 8 50 0~-0.030 h5 2 G9B80012 1.2 4 1.8 6 50 0~-0.030 h5 2 G9B80012 1.2 4 1.8 6 50 0~-0.030 h5 2 G9B80015 1.5 4 2.3 6 50 0~-0.030 h5 2 G9B80015 1.5 4 2.3 6 50 0~-0.030 h5 2 G9B80020 2 4 3 6 50 0~-0.030 h5 2 G9B80020 2 4 3 6 50 0~-0.030 h5 2 G9B80040 4 6 6 12 50 0~-0.030 h5 2 G9B80040 4 6 6 12 50 0~-0.030 h5 2 G9B80901 0.4 4 0.7 4 50 0~-0.030 h5 2 G9B80901 0.4 4 0.7 4 50 0~-0.030 h5 2 G9B80902 0.5 4 0.75 4 50 0~-0.030 h5 2 G9B80902 0.5 4 0.75 4 50 0~-0.030 h5 2 G9B80905 0.6 4 0.9 6 50 0~-0.030 h5 2 G9B80905 0.6 4 0.9 6 50 0~-0.030 h5 2 G9B80907 0.8 4 1.2 6 50 0~-0.030 h5 2 G9B80907 0.8 4 1.2 6 50 0~-0.030 h5 2 G9B80908 0.8 4 1.2 8 50 0~-0.030 h5 2 G9B80908 0.8 4 1.2 8 50 0~-0.030 h5 2 G9B80914 1.2 4 1.8 8 50 0~-0.030 h5 2 G9B80914 1.2 4 1.8 8 50 0~-0.030 h5 2 G9B80915 1.2 4 1.8 10 50 0~-0.030 h5 2 G9B80915 1.2 4 1.8 10 50 0~-0.030 h5 2 G9B80916 1.2 4 1.8 12 50 0~-0.030 h5 2 G9B80916 1.2 4 1.8 12 50 0~-0.030 h5 2 G9B80917 1.5 4 2.3 8 50 0~-0.030 h5 2 G9B80917 1.5 4 2.3 8 50 0~-0.030 h5 2 G9B80918 1.5 4 2.3 10 50 0~-0.030 h5 2 G9B80918 1.5 4 2.3 10 50 0~-0.030 h5 2 G9B80920 1.5 4 2.3 14 50 0~-0.030 h5 2 G9B80920 1.5 4 2.3 14 50 0~-0.030 h5 2 G9B80922 1.5 4 2.3 18 50 0~-0.030 h5 2 G9B80922 1.5 4 2.3 18 50 0~-0.030 h5 2 G9B80926 2 4 3 12 50 0~-0.030 h5 2 G9B80926 2 4 3 12 50 0~-0.030 h5 2 G9B80928 2 4 3 16 50 0~-0.030 h5 2 G9B80928 2 4 3 16 50 0~-0.030 h5 2 G9B80930 2 4 3 20 50 0~-0.030 h5 2 G9B80930 2 4 3 20 50 0~-0.030 h5 2 G9B80932 2.5 4 3.7 16 50 0~-0.030 h5 2 G9B80932 2.5 4 3.7 16 50 0~-0.030 h5 2 G9B80934 3 6 4.5 12 50 0~-0.030 h5 2 G9B80934 3 6 4.5 12 50 0~-0.030 h5 2 G9B80936 3 6 4.5 20 60 0~-0.030 h5 2 G9B80936 3 6 4.5 20 60 0~-0.030 h5 2 G9B80941 4 6 6 30 75 0~-0.030 h5 2 G9B80941 4 6 6 30 75 0~-0.030 h5 2
Side Milling
Small Part
Slotting
Die Sinking
Facing
P Carbon Steels

Excellent

Good Great Excellent
P Alloy Steels

Excellent

Good Great Excellent
P Prehardened Steels

Excellent

Good Great Excellent
M Stainless Steels

Great

Good Great Excellent
K Cast Iron

Great

Good Great Excellent
H Hardened Steels (HRc40~45)

Great

Good Great Excellent
P

Non-alloy steel

Excellent Excellent
HRc
13252832
HB
125190250270300
P

Low alloy steel

Excellent Excellent
HRc
10293238
HB
180275300350
P

High alloy & tool steel

Excellent Excellent
HRc
1535
HB
200325
M

Stainless steel

Good Good
HRc
152310
HB
200240180
K

Grey cast iron

Good Good
HRc
1026
HB
180260
K

Nodular cast iron

Good Good
HRc
325
HB
160250
K

Malleable cast iron

Good Good
HRc
21
HB
130230
N

Aluminium. wrought

Good Good
HRc
HB
60100
N

Aluminium. cast

Good Good
HRc
HB
7590130
N

Copper. bronze. brass

Good Good
HRc
HB
11090

Speeds & Feeds

ISO VDI 3323  Material Description Parameter Diameter (Ø)
1.2 1.4 1.5 1.6 1.8 2.0 2.5 3.0 4.0
P 1-4 Non-Alloy Steel Vc 58~72 60~75 59~73 60~75 62~79 63~79 63~79 64~80 64~82
fz 0.008~0.020 0.009~0.023 0.010~0.025 0.010~0.026 0.011~0.027 0.012~0.031 0.015~0.038 0.018~0.045 0.024~0.059
RPM 15500~19000 13600~17000 12500~15500 12000~15000 11000~14000 10000~12500 8000~10000 6800~8500 5100~6500
FEED 240~765 240~765 240~765 240~765 240~765 240~765 240~765 240~765 240~765
Ap 0.055~0.100 0.062~0.125 0.070~0.135 0.075~0.145 0.080~0.160 0.090~0.180 0.112~0.235 0.135~0.270 0.180~0.360
5 Vc 41~53 43~53 42~54 44~55 44~55 44~56 45~57 44~57 44~57
fz 0.007~0.018 0.008~0.021 0.009~0.022 0.009~0.023 0.010~0.026 0.011~0.028 0.014~0.035 0.017~0.043 0.023~0.057
RPM 11000~14000 9800~12000 8950~11500 8700~10900 7800~9800 7000~8950 5700~7200 4700~6000 3500~4500
FEED 160~510 160~510 160~510 160~510 160~510 160~510 160~510 160~510 160~510
Ap 0.055~0.100 0.062~0.125 0.070~0.135 0.075~0.145 0.080~0.160 0.090~0.180 0.112~0.235 0.135~0.270 0.180~0.360
6-7 Low-Alloy Steel Vc 58~72 60~75 59~73 60~75 62~79 63~79 63~79 64~80 64~82
fz 0.008~0.020 0.009~0.023 0.010~0.025 0.010~0.026 0.011~0.027 0.012~0.031 0.015~0.038 0.018~0.045 0.024~0.059
RPM 15500~19000 13600~17000 12500~15500 12000~15000 11000~14000 10000~12500 8000~10000 6800~8500 5100~6500
FEED 240~765 240~765 240~765 240~765 240~765 240~765 240~765 240~765 240~765
Ap 0.055~0.100 0.062~0.125 0.070~0.135 0.075~0.145 0.080~0.160 0.090~0.180 0.112~0.235 0.135~0.270 0.180~0.360
8-9 Vc 41~53 43~53 42~54 44~55 44~55 44~56 45~57 44~57 44~57
fz 0.007~0.018 0.008~0.021 0.009~0.022 0.009~0.023 0.010~0.026 0.011~0.028 0.014~0.035 0.017~0.043 0.023~0.057
RPM 11000~14000 9800~12000 8950~11500 8700~10900 7800~9800 7000~8950 5700~7200 4700~6000 3500~4500
FEED 160~510 160~510 160~510 160~510 160~510 160~510 160~510 160~510 160~510
Ap 0.055~0.100 0.062~0.125 0.070~0.135 0.075~0.145 0.080~0.160 0.090~0.180 0.112~0.235 0.135~0.270 0.180~0.360
10 High-Alloyed Steel, and Tool Steel Vc 58~72 60~75 59~73 60~75 62~79 63~79 63~79 64~80 64~82
fz 0.008~0.020 0.009~0.023 0.010~0.025 0.010~0.026 0.011~0.027 0.012~0.031 0.015~0.038 0.018~0.045 0.024~0.059
RPM 15500~19000 13600~17000 12500~15500 12000~15000 11000~14000 10000~12500 8000~10000 6800~8500 5100~6500
FEED 240~765 240~765 240~765 240~765 240~765 240~765 240~765 240~765 240~765
Ap 0.055~0.100 0.062~0.125 0.070~0.135 0.075~0.145 0.080~0.160 0.090~0.180 0.112~0.235 0.135~0.270 0.180~0.360
11.1-11.2 Vc 41~53 43~53 42~54 44~55 44~55 44~56 45~57 44~57 44~57
fz 0.007~0.018 0.008~0.021 0.009~0.022 0.009~0.023 0.010~0.026 0.011~0.028 0.014~0.035 0.017~0.043 0.023~0.057
RPM 11000~14000 9800~12000 8950~11500 8700~10900 7800~9800 7000~8950 5700~7200 4700~6000 3500~4500
FEED 160~510 160~510 160~510 160~510 160~510 160~510 160~510 160~510 160~510
Ap 0.055~0.100 0.062~0.125 0.070~0.135 0.075~0.145 0.080~0.160 0.090~0.180 0.112~0.235 0.135~0.270 0.180~0.360
RPM: – rev/min
FEED: – mm/min
Vc: – m/min
Fz: – mm/tooth
EDP No. Mill Diameter ShankDia Length of Cut Length Below Shank Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9B80005 0.5 4 0.75 2 50 0~-0.030 h5 2 G9B80005 0.5 4 0.75 2 50 0~-0.030 h5 2 G9B80007 0.7 4 1.1 4 50 0~-0.030 h5 2 G9B80007 0.7 4 1.1 4 50 0~-0.030 h5 2 G9B80009 0.9 4 1.4 8 50 0~-0.030 h5 2 G9B80009 0.9 4 1.4 8 50 0~-0.030 h5 2 G9B80012 1.2 4 1.8 6 50 0~-0.030 h5 2 G9B80012 1.2 4 1.8 6 50 0~-0.030 h5 2 G9B80015 1.5 4 2.3 6 50 0~-0.030 h5 2 G9B80015 1.5 4 2.3 6 50 0~-0.030 h5 2 G9B80020 2 4 3 6 50 0~-0.030 h5 2 G9B80020 2 4 3 6 50 0~-0.030 h5 2 G9B80040 4 6 6 12 50 0~-0.030 h5 2 G9B80040 4 6 6 12 50 0~-0.030 h5 2 G9B80901 0.4 4 0.7 4 50 0~-0.030 h5 2 G9B80901 0.4 4 0.7 4 50 0~-0.030 h5 2 G9B80902 0.5 4 0.75 4 50 0~-0.030 h5 2 G9B80902 0.5 4 0.75 4 50 0~-0.030 h5 2 G9B80905 0.6 4 0.9 6 50 0~-0.030 h5 2 G9B80905 0.6 4 0.9 6 50 0~-0.030 h5 2 G9B80907 0.8 4 1.2 6 50 0~-0.030 h5 2 G9B80907 0.8 4 1.2 6 50 0~-0.030 h5 2 G9B80908 0.8 4 1.2 8 50 0~-0.030 h5 2 G9B80908 0.8 4 1.2 8 50 0~-0.030 h5 2 G9B80914 1.2 4 1.8 8 50 0~-0.030 h5 2 G9B80914 1.2 4 1.8 8 50 0~-0.030 h5 2 G9B80915 1.2 4 1.8 10 50 0~-0.030 h5 2 G9B80915 1.2 4 1.8 10 50 0~-0.030 h5 2 G9B80916 1.2 4 1.8 12 50 0~-0.030 h5 2 G9B80916 1.2 4 1.8 12 50 0~-0.030 h5 2 G9B80917 1.5 4 2.3 8 50 0~-0.030 h5 2 G9B80917 1.5 4 2.3 8 50 0~-0.030 h5 2 G9B80918 1.5 4 2.3 10 50 0~-0.030 h5 2 G9B80918 1.5 4 2.3 10 50 0~-0.030 h5 2 G9B80920 1.5 4 2.3 14 50 0~-0.030 h5 2 G9B80920 1.5 4 2.3 14 50 0~-0.030 h5 2 G9B80922 1.5 4 2.3 18 50 0~-0.030 h5 2 G9B80922 1.5 4 2.3 18 50 0~-0.030 h5 2 G9B80926 2 4 3 12 50 0~-0.030 h5 2 G9B80926 2 4 3 12 50 0~-0.030 h5 2 G9B80928 2 4 3 16 50 0~-0.030 h5 2 G9B80928 2 4 3 16 50 0~-0.030 h5 2 G9B80930 2 4 3 20 50 0~-0.030 h5 2 G9B80930 2 4 3 20 50 0~-0.030 h5 2 G9B80932 2.5 4 3.7 16 50 0~-0.030 h5 2 G9B80932 2.5 4 3.7 16 50 0~-0.030 h5 2 G9B80934 3 6 4.5 12 50 0~-0.030 h5 2 G9B80934 3 6 4.5 12 50 0~-0.030 h5 2 G9B80936 3 6 4.5 20 60 0~-0.030 h5 2 G9B80936 3 6 4.5 20 60 0~-0.030 h5 2 G9B80941 4 6 6 30 75 0~-0.030 h5 2 G9B80941 4 6 6 30 75 0~-0.030 h5 2
