New

TANK-POWER Multi Flute 30°Helix Short Roughing (Fine) End Mill (GA941)

  • $0.00INC GST $0.00 EX GST
TANK-POWER Multi Flute 30°Helix Short Roughing (Fine) End Mill (GA941)
TANK-POWER Multi Flute 30°Helix Short Roughing (Fine) End Mill (GA941)
New

TANK-POWER Multi Flute 30°Helix Short Roughing (Fine) End Mill (GA941)

  • $0.00INC GST $0.00 EX GST Price available on request

Code: GA941060

P M K N
Mill Diameter (mm)
Chamfer (mm)
Loading stock…
Buy Local
Minimum order: $200.00
$200.00 to go
Spend $200.00 or more to enable checkout.
South Korea Made in South Korea
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

SKUMill Diameter (mm)Chamfer (mm)Overall length (mm)Shank diameter (mm)FlutesLength of cut (mm)Stock Price Qty Add
GA94106060.1857.06.0313.0 5 days -
GA94107070.1866.010.0316.0 5 days -
GA94108080.1869.010.0319.0 5 days -
GA94109090.1869.010.0319.0 5 days -
GA941100100.1872.010.0422.0 5 days -
GA941120120.1883.012.0426.0 5 days -
GA941140140.2583.012.0426.0 5 days -
GA941160160.2592.016.0432.0 5 days -
GA941180180.2592.016.0432.0 5 days -
GA941200200.25104.020.0438.0 5 days -
GA941220220.36104.020.0538.0 5 days -
GA941250250.36121.025.0545.0 5 days -

Add TANK-POWER Multi Flute 30°Helix Short Roughing (Fine) End Mill (GA941) to comparison

View Comparison
  • Overview
  • Specifications
  • Specifications
  • Operation
  • Work Material
  • Reviews
Product Description
  • Suitable for high-feed roughing milling.
  • Designed to machine carbon steels, alloyed steels, stainless steels.
  • Providing excellent finished surfaces in many cases.
  • YG-1’s new developed TANK-POWER Coating suitable for high
    speed cutting.
  • up to Ø20 : center cut, over Ø20 : non center cut
Product Data
Workpiece Material P M K N
Chamfer Angle 45
Cutting Shape Roughing
Helix Angle Square 30
No. Flutes 3-5
Operation Die Sinking, Facing, Side Milling, Slotting, Small Part
Periphery Type Roughing - Fine
Shank Type 1835B
Surface Treatment YG-1 X Coating
Tool Material YPM
Tool Standard DIN 844
Flutes Multi Flute
Helix Angle 30°
Cutting Edge Shape ROUGHING
Size Min D6.0
Size Max D25.0
Length

Short Length
Coating X-Coating



EDP No. Mill Diameter (D1) ShankDia (D2) Length of Cut (L1) Overall Length (L2) Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute GA941060 6 6 13 57 js12 h6 3 GA941070 7 10 16 66 js12 h6 3 GA941080 8 10 19 69 js12 h6 3 GA941090 9 10 19 69 js12 h6 3 GA941100 10 10 22 72 js12 h6 4 GA941120 12 12 26 83 js12 h6 4 GA941140 14 12 26 83 js12 h6 4 GA941160 16 16 32 92 js12 h6 4 GA941180 18 16 32 92 js12 h6 4 GA941200 20 20 38 104 js12 h6 4 GA941220 22 20 38 104 js12 h6 5 GA941250 25 25 45 121 js12 h6 5
Side Milling
Small Part
Slotting
Die Sinking
Facing
P Carbon Steels

Excellent

Good Great Excellent
P Alloy Steels

Excellent

Good Great Excellent
P Prehardened Steels

Great

Good Great Excellent
M Stainless Steels

Excellent

Good Great Excellent
K Cast Iron

Excellent

Good Great Excellent
N Copper

Great

Good Great Excellent
EDP No. Mill Diameter (D1) ShankDia (D2) Length of Cut (L1) Overall Length (L2) Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute GA941060 6 6 13 57 js12 h6 3 GA941070 7 10 16 66 js12 h6 3 GA941080 8 10 19 69 js12 h6 3 GA941090 9 10 19 69 js12 h6 3 GA941100 10 10 22 72 js12 h6 4 GA941120 12 12 26 83 js12 h6 4 GA941140 14 12 26 83 js12 h6 4 GA941160 16 16 32 92 js12 h6 4 GA941180 18 16 32 92 js12 h6 4 GA941200 20 20 38 104 js12 h6 4 GA941220 22 20 38 104 js12 h6 5 GA941250 25 25 45 121 js12 h6 5
