YG1001
P01–P10
K10–K25
CVD TiCN–Al₂O₃
Stable Machining of Cast Iron
- Substrate designed for high wear resistance
- Thick Al₂O₃ ensures good wear at high speeds, including dry cutting
New
Made in South Korea
WNMG-UG Medium Machining (Stable) Turning Insert (80° Trigonal Negative)
Code: 22000056
Made in South Korea
If you're not 100% happy with your purchase, we'll replace or refund.
| SKU | Designation | Grade | Inner Circle (mm) | Corner radius (mm) | Thickness (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|
| 22000056 | WNMG 080408 | YG801 | 12.7 | 0.8 | 4.76 | In stock | $11.60 | ||
| 22000059 | WNMG 060408 | YG801 | 9.525 | 0.8 | 4.76 | In stock | $9.90 | ||
| 22000147 | WNMG 080408 | YG3010 | 12.7 | 0.8 | 4.76 | 5 days | $12.70 | ||
| 22000148 | WNMG 080408 | YG3020 | 12.7 | 0.8 | 4.76 | In stock | $12.70 | ||
| 22000149 | WNMG 080408 | YG3030 | 12.7 | 0.8 | 4.76 | 5 days | $12.70 | ||
| 22000318 | WNMG 080404 | YG3010 | 12.7 | 0.4 | 4.76 | 5 days | $12.70 | ||
| 22000319 | WNMG 080404 | YG3020 | 12.7 | 0.4 | 4.76 | In stock | $12.70 | ||
| 22000320 | WNMG 080404 | YG3030 | 12.7 | 0.4 | 4.76 | 5 days | $12.70 | ||
| 22000438 | WNMG 060408 | YG3020 | 9.525 | 0.8 | 4.76 | 5 days | $10.90 | ||
| 22000463 | WNMG 080408 | YG1001 | 12.7 | 0.8 | 4.76 | 5 days | $11.60 | ||
| 22000466 | WNMG 080412 | YG1001 | 12.7 | 1.2 | 4.76 | 5 days | $11.60 | ||
| 22000490 | WNMG 080412 | YG3020 | 12.7 | 1.2 | 4.76 | 5 days | $12.70 | ||
| 22000503 | WNMG 080412 | YG3010 | 12.7 | 1.2 | 4.76 | 5 days | $12.70 | ||
| 22000583 | WNMG 080416 | YG3020 | 12.7 | 1.6 | 4.76 | 5 days | $12.70 | ||
| 22000697 | WNMG 060408 | YG1001 | 9.525 | 0.8 | 4.76 | 5 days | $9.90 |
Turning Grades
YG3010
P05–P20
K15–K35
CVD TiCN–Al₂O₃
Finishing Steels & Ductile Cast Iron
- Finishing/light machining under stable conditions
- New Al₂O₃ + post-treatment improves wear and surface smoothness
YG3020
P15–P30
CVD TiCN–Al₂O₃
General Steel Application
- Substrate engineered for good toughness
- Excellent surface smoothness and reliability
YG3030
P20–P35
M10-M30
CVD TiCN–Al₂O₃
Interrupted Cutting of Steel & Stainless
- Roughing in mild & low-carbon alloy steels
- Optimized post-treatment balances wear & chipping resistance
YG801
P10–P30
PVD–TiAlSiN
Carbon Steel at Low Cutting Speed
- Recommended for mild steel and boring
- Special PVD coating delivers excellent wear resistance
P
Steels
M
Stainless Steels
K
Cast Iron
Add WNMG-UG Medium Machining (Stable) Turning Insert (80° Trigonal Negative) to comparison
View Comparison- Overview
- Reviews
Product Description
Product Data
| Chip Breaker | UG |
| Corner Radius | 0.4, 0.8, 1.2, 1.6 |
| Turning Grade | YG1001, YG3010, YG3020, YG3030, YG801 |
