(EI451) D-Power Carbide 2Flute Ball Nose End Mill, Long Length Neck for Graphite (Diamond Coated)
Diamond-coated long-length ball nose end mill for graphiteCode: EI451020
-
Key Features
- Diamond-coated carbide construction for graphite machining
- Two-flute ball nose geometry with long-length neck
- Plain-shank sizes from 2 to 12 mm diameter
Made in South Korea
Designed for graphite
Diamond-coated carbide construction is specified for high-performance machining of graphite.
Reach contoured features
Long-length neck geometry combines ball nose profiling capability with extended reach.
Select the required radius
Choose from R1.0 to R6.0 ball radii across the matched EI451 variants.
| SKU | Mill Diameter (mm) | Ball Nose Radius (mm) | Overall length (mm) | Shank dia. (mm) | Length of cut (mm) | Length below shank (mm) | Neck dia. (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|---|---|
| EI451020 | 2 | R1.0 | 80.0 | 4.0 | 10.0 | 20.0 | 1.95 | Low stock | $148.60 | ||
| EI451030 | 3 | R1.5 | 80.0 | 4.0 | 15.0 | 25.0 | 2.9 | Low stock | $137.90 | ||
| EI451040 | 4 | R2.0 | 80.0 | 4.0 | 20.0 | 30.0 | 3.9 | 5 days | $137.90 | ||
| EI451050 | 5 | R2.5 | 100.0 | 6.0 | 30.0 | 50.0 | 4.9 | 5 days | $176.40 | ||
| EI451060 | 6 | R3.0 | 100.0 | 6.0 | 30.0 | 50.0 | 5.5 | 5 days | $176.40 | ||
| EI451080 | 8 | R4.0 | 110.0 | 8.0 | 40.0 | 60.0 | 7.5 | 5 days | $224.20 | ||
| EI451100 | 10 | R5.0 | 120.0 | 10.0 | 50.0 | 70.0 | 9.5 | Low stock | $291.60 | ||
| EI451120 | 12 | R6.0 | 130.0 | 12.0 | 55.0 | 75.0 | 11.5 | 5 days | $373.80 |
Add (EI451) D-Power Carbide 2Flute Ball Nose End Mill, Long Length Neck for Graphite (Diamond Coated) to comparison
View Comparison- Overview
- Specifications
- Reviews
YG-1 EI451 D-Power is a diamond-coated carbide two-flute ball nose end mill with a long-length neck. Designed for graphite machining, its ball nose geometry supports smooth, excellent surface finishes on suitable work materials. The diamond coating provides high hardness and excellent wear resistance for abrasive machining applications. Use it for graphite, wrought aluminium, bakelite, plastics, wood, brass and other non-ferrous or non-metallic materials. Plain-shank variants cover R1.0 to R6.0 ball radii, with ball-radius tolerance of ±0.01 mm. Selected diameters range from 2 to 12 mm, supporting small-part profiling and side-milling operations. The range includes 80 to 130 mm overall lengths.
- Diamond-coated carbide construction for graphite machining
- Two-flute ball nose geometry with long-length neck
- Plain-shank sizes from 2 to 12 mm diameter
- Ball radii from R1.0 to R6.0
- Ball-radius tolerance of ±0.01 mm
- Suitable for graphite and selected non-ferrous or non-metallic materials
No specifications available.
