(EIB87) D-Power Carbide 2Flute Ball Nose End Mill, Taper Neck for Graphite (Diamond Coated)
Diamond coated taper neck ball nose end mill for graphiteCode: EIB87010
-
Key Features
- Diamond coated carbide construction
- Two flute ball nose geometry
- Taper neck design for detailed profiling
Made in South Korea
Graphite focused cutting
Diamond coated ball nose geometry is designed for graphite machining applications.
Detailed profile capability
Small ball nose radii and a taper neck support precise profiling work.
Abrasion resistant coating
High film hardness and excellent wear resistance suit abrasive work materials.
| SKU | Mill Diameter (mm) | Ball Nose Radius (mm) | Overall length (mm) | Shank dia. (mm) | Length of cut (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|
| EIB87010 | 1 | R0.5 | 40.0 | 3.0 | 2.0 | 5 days | $98.70 | ||
| EIB87015 | 1.5 | R0.75 | 40.0 | 3.0 | 3.0 | 5 days | $98.80 | ||
| EIB87020 | 2 | R1.0 | 40.0 | 3.0 | 4.0 | 5 days | $99.10 |
Add (EIB87) D-Power Carbide 2Flute Ball Nose End Mill, Taper Neck for Graphite (Diamond Coated) to comparison
View Comparison- Overview
- Specifications
- Reviews
YG-1 EIB87 D-Power carbide two flute ball nose end mills feature a diamond coating and taper neck. They are designed for graphite machining, supporting smooth surface finishes on suitable work materials. The diamond coating combines high film hardness with excellent wear resistance for abrasive machining applications. These plain shank tools also suit non-ferrous metals and non-metallic materials. Available variants provide R0.5, R0.75 and R1.0 radii, each with 40 mm overall length. The listed variants use 3 mm shanks, with ball nose radius tolerance of ±0.01 mm. Taper neck angles range from 4° 15´ to 8° 30´ within this selected variant group. This geometry supports detailed profiling where smaller radii are required.
- Diamond coated carbide construction
- Two flute ball nose geometry
- Taper neck design for detailed profiling
- Plain shank configuration
- R0.5 to R1.0 ball nose radii
- ±0.01 mm ball nose radius tolerance
