(GYG76) HSS-PM, Only One 4Flute Coated End Mill, Long Length, Plain Shank

  • $30.36INC GST $27.60 EX GST
(GYG76) HSS-PM, Only One 4Flute Coated End Mill, Long Length, Plain Shank

(GYG76) HSS-PM, Only One 4Flute Coated End Mill, Long Length, Plain Shank

  • $30.36INC GST $27.60 EX GST

Code: GYG76030

P M K N
Mill Diameter (mm)
Loading stock…
Buy Local
Minimum order: $200.00
$200.00 to go
Spend $200.00 or more to enable checkout.
South Korea Made in South Korea
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

SKUMill Diameter (mm)Overall length (mm)Shank dia. (mm)Length of cut (mm)Stock Price Qty Add
GYG76030356.06.012.0 5 days $27.60
GYG76040463.06.019.0 5 days $27.60
GYG76050568.06.024.0 5 days $27.60
GYG76060668.06.024.0 5 days $27.60
GYG76070780.08.030.0 5 days $47.20
GYG76080888.08.038.0 5 days $47.20
GYG761001095.010.045.0 5 days $52.10
GYG7612012110.012.053.0 5 days $80.00
GYG7614014110.012.053.0 5 days $108.80
GYG7616016123.016.063.0 5 days $139.00

Add (GYG76) HSS-PM, Only One 4Flute Coated End Mill, Long Length, Plain Shank to comparison

View Comparison
  • Overview
  • Specifications
  • Specifications
  • Operation
  • Work Material
  • Reviews
Product Description

Product Data
Workpiece Material P M K N
Cutting Shape Square
Hardened Steels(HRc40~45) Great
Helix Angle Square 30
Length Long
No. Flutes 4
Operation Die Sinking, Facing, Side Milling, Slotting, Small Part
Shank Type Plain
Surface Treatment YG-1 Y Coating
Tool Material PM 60
Flutes 4
Helix Angle 30°
Cutting Edge Shape SQUARE
Size Min D2.0
Size Max D25.0
Length LONG LENGTH (Center Cut)
Coating Y-Coating

EDP No. Mill Diameter (D1) ShankDia (D2) Length of Cut (L1) Overall Length (L2) Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute GYG76020 2 6 10 54 0~-0.030 h6 4 GYG76030 3 6 12 56 0~-0.030 h6 4 GYG76040 4 6 19 63 0~-0.030 h6 4 GYG76050 5 6 24 68 0~-0.030 h6 4 GYG76060 6 6 24 68 0~-0.030 h6 4 GYG76070 7 8 30 80 0~-0.030 h6 4 GYG76080 8 8 38 88 0~-0.030 h6 4 GYG76090 9 10 38 88 0~-0.030 h6 4 GYG76100 10 10 45 95 0~-0.030 h6 4 GYG76120 12 12 53 110 0~-0.030 h6 4 GYG76140 14 12 53 110 0~-0.030 h6 4 GYG76160 16 16 63 123 0~-0.030 h6 4 GYG76180 18 16 63 123 0~-0.030 h6 4 GYG76200 20 20 75 141 0~-0.030 h6 4 GYG76220 22 20 75 141 0~-0.030 h6 4 GYG76250 25 25 90 166 0~-0.030 h6 4
Side Milling
Small Part
Slotting
Die Sinking
Facing
P Carbon Steels

Excellent

Good Great Excellent
P Alloy Steels

Excellent

Good Great Excellent
P Prehardened Steels

Great

Good Great Excellent
M Stainless Steels

Excellent

Good Great Excellent
K Cast Iron

Excellent

Good Great Excellent
N Copper

Great

Good Great Excellent
H Hardened Steels (HRc40~45)

Great

Good Great Excellent
P

Non-alloy steel

Excellent Excellent
HRc
13252832
HB
125190250270300
P

Low alloy steel

Excellent Excellent
HRc
10293238
HB
180275300350
P

High alloy & tool steel

Excellent Excellent
HRc
1535
HB
200325
M

Stainless steel

Excellent Excellent
HRc
152310
HB
200240180
K

Grey cast iron

Excellent Excellent
HRc
1026
HB
180260
K

Nodular cast iron

Excellent Excellent
HRc
325
HB
160250
K

Malleable cast iron

Excellent Excellent
HRc
21
HB
130230
N

Copper. bronze. brass

Good Good
HRc
HB
11090100
H

Hardened steels & cast irons

Good Good
HRc
40
HB
630
EDP No. Mill Diameter (D1) ShankDia (D2) Length of Cut (L1) Overall Length (L2) Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute GYG76020 2 6 10 54 0~-0.030 h6 4 GYG76030 3 6 12 56 0~-0.030 h6 4 GYG76040 4 6 19 63 0~-0.030 h6 4 GYG76050 5 6 24 68 0~-0.030 h6 4 GYG76060 6 6 24 68 0~-0.030 h6 4 GYG76070 7 8 30 80 0~-0.030 h6 4 GYG76080 8 8 38 88 0~-0.030 h6 4 GYG76090 9 10 38 88 0~-0.030 h6 4 GYG76100 10 10 45 95 0~-0.030 h6 4 GYG76120 12 12 53 110 0~-0.030 h6 4 GYG76140 14 12 53 110 0~-0.030 h6 4 GYG76160 16 16 63 123 0~-0.030 h6 4 GYG76180 18 16 63 123 0~-0.030 h6 4 GYG76200 20 20 75 141 0~-0.030 h6 4 GYG76220 22 20 75 141 0~-0.030 h6 4 GYG76250 25 25 90 166 0~-0.030 h6 4
