Code: GM819030
Made in South Korea
| SKU | Mill Diameter (mm) | Corner Radius (mm) | Overall length (mm) | Shank dia. (mm) | Flutes | Length of cut (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|---|
| GM819030 | 3.0 | R0.3 | 50.0 | 6.0 | 4 | 12.0 | In stock | $75.60 | ||
| GM819911 | 4.0 | R0.5 | 50.0 | 6.0 | 4 | 15.0 | In stock | $75.60 | ||
| GM819912 | 5.0 | R0.5 | 60.0 | 6.0 | 4 | 20.0 | 5 days | $100.80 | ||
| GM819060 | 6.0 | R0.5 | 60.0 | 6.0 | 4 | 20.0 | In stock | $75.60 | ||
| GM819901 | 6.0 | R1.0 | 60.0 | 6.0 | 4 | 20.0 | In stock | $75.60 | ||
| GM819080 | 8.0 | R0.5 | 70.0 | 8.0 | 4 | 25.0 | 5 days | $128.90 | ||
| GM819902 | 8.0 | R1.0 | 70.0 | 8.0 | 4 | 25.0 | 5 days | $128.90 | ||
| GM819904 | 8.0 | R2.0 | 70.0 | 8.0 | 4 | 25.0 | 5 days | $140.70 | ||
| GM819100 | 10.0 | R0.5 | 90.0 | 10.0 | 4 | 30.0 | 5 days | $190.70 | ||
| GM819905 | 10.0 | R1.0 | 90.0 | 10.0 | 4 | 30.0 | Low stock | $143.30 | ||
| GM819906 | 10.0 | R1.5 | 90.0 | 10.0 | 4 | 30.0 | 5 days | $208.00 | ||
| GM819907 | 10.0 | R2.0 | 90.0 | 10.0 | 4 | 30.0 | 5 days | $208.00 | ||
| GM819120 | 12.0 | R0.5 | 90.0 | 12.0 | 4 | 30.0 | Low stock | $180.90 | ||
| GM819908 | 12.0 | R1.0 | 90.0 | 12.0 | 4 | 30.0 | 5 days | $261.70 | ||
| GM819909 | 12.0 | R1.5 | 90.0 | 12.0 | 4 | 30.0 | Low stock | $197.30 | ||
| GM819910 | 12.0 | R2.0 | 90.0 | 12.0 | 4 | 30.0 | In stock | $197.30 | ||
| GM819160 | 16.0 | R0.5 | 110.0 | 16.0 | 4 | 50.0 | In stock | $366.80 | ||
| GM819916 | 16.0 | R1.0 | 110.0 | 16.0 | 4 | 50.0 | Low stock | $366.80 | ||
| GM819918 | 16.0 | R2.0 | 110.0 | 16.0 | 4 | 50.0 | Low stock | $400.10 | ||
| GM819921 | 20.0 | R2.0 | 110.0 | 20.0 | 4 | 55.0 | 5 days | $883.10 |
Add (GM819) X-Power Pro Carbide 4Flute Corner Radius End Mill, Long Length to comparison
View ComparisonX-POWER PRO 4 Flute 30° Helix Long Corner Radius End Mill GM819 balances reach and reliability. Advanced ‘Z Coating’ with an ultrafine micrograin carbide substrate supports long life in wet or dry cutting. It machines steels, stainless steel, cast iron, and hardened steels to 55 Rockwell with accuracy. Compared to the original X-Power, expect 20–30% longer life and over 20% faster cutting. Corner radius edges enhance durability and surface finish during high speed, high precision milling.
| Workpiece Material | P M K H |
| Cutting Shape | Corner Radius |
| Hardened Steels(HRc40~45) | Excellent |
| Helix Angle | Square 30 |
| Length | Long |
| No. Flutes | 4 |
| Operation | Corner, Die Sinking, Facing, Helical-Interpol, Side Milling, Slotting, Small Part |
| Shank Type | Plain |
| Surface Treatment | YG-1 Y Coating |
| Tool Material | Carbide |
| Flutes | 4 |
| Helix Angle | 30° |
| Cutting Edge Shape | CORNER RADIUS |
| Size Min | D3.0 |
| Size Max | D20.0 |
| Length |
Long Length |
| Coating | Y-Coating |
