(G9553) K-2 Carbide, 3Flute End Mill, Short Length throw Away, Flat Shank

  • $31.02INC GST $28.20 EX GST
(G9553) K-2 Carbide, 3Flute End Mill, Short Length throw Away, Flat Shank
(G9553) K-2 Carbide, 3Flute End Mill, Short Length throw Away, Flat Shank

(G9553) K-2 Carbide, 3Flute End Mill, Short Length throw Away, Flat Shank

  • $31.02INC GST $28.20 EX GST

Code: G9553005

P M K S
Mill Diameter (mm)
Loading stock…
Buy Local
Minimum order: $200.00
$200.00 to go
Spend $200.00 or more to enable checkout.
South Korea Made in South Korea
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

SKUMill Diameter (mm)Overall length (mm)Shank dia. (mm)Length of cut (mm)Stock Price Qty Add
G95530050.538.03.01.5 5 days $28.20
G95530060.638.03.01.5 5 days $28.20
G95530080.838.03.02.0 5 days $24.90
G9553010138.03.02.0 5 days $22.60
G95530121.238.03.02.0 5 days $25.80
G95530151.538.03.02.0 5 days $22.60
G95530181.838.03.02.0 5 days $29.40

Add (G9553) K-2 Carbide, 3Flute End Mill, Short Length throw Away, Flat Shank to comparison

View Comparison
  • Overview
  • Specifications
  • Specifications
  • Operation
  • Work Material
  • Speeds & Feeds
  • Reviews
Product Description

The G9553/G9410 series K2 coated carbide milling cutters feature 3 flutes making them suitable for slotting & profiling applications. K2 carbide range from global market leaders YG-1 are the number 1 best selling tool for general purpose milling. Ideal for general milling steel <45HRc, stainless steel, cast iron, copper & aluminium.

  • 3 flutes for slotting & profiling applications
  • Special K2 coating for longer tool life, high heat and wear resistance
  • Dry cutting on steel can increase tool life up to 40%
  • Also suitable for general milling of steel, stainless steel, cast iron & non-ferrous
  • Consistent and reliable performance in general machining conditions
  • Made from high-quality micrograin carbide.
  • Manufactured by global market leader YG-1
Product Data
Workpiece Material P M K S
Cutting Shape Square
Helix Angle 30
Length Short, Throw Away
No. Flutes 3
Operation Die Sinking, Facing, Side Milling, Slotting, Small Part
Shank Type Plain YG-1 Standard
Surface Treatment Titanium Aluminium Nitride Coating
Tool Material Carbide
Flutes 4
Helix Angle 30°
Cutting Edge Shape
SQUARE
Size Min D3.5
Size Max D20.0
Length
LONG LENGTH
Coating
TiAlN
EDP No. Mill Diameter ShankDia Length of Cut Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9553005 0.5 3 1.5 38 0~-0.030 h5 3 G9553006 0.6 3 1.5 38 0~-0.030 h5 3 G9553008 0.8 3 2 38 0~-0.030 h5 3 G9553010 1 3 2 38 0~-0.030 h5 3 G9553012 1.2 3 2 38 0~-0.030 h5 3 G9553015 1.5 3 2 38 0~-0.030 h5 3 G9553018 1.8 3 2 38 0~-0.030 h5 3
Side Milling
Small Part
Slotting
Die Sinking
Facing
P Carbon Steels

Excellent

Good Great Excellent
P Alloy Steels

Excellent

Good Great Excellent
P Prehardened Steels

Excellent

Good Great Excellent
M Stainless Steels

Great

Good Great Excellent
K Cast Iron

Great

Good Great Excellent
S Inconel

Great

Good Great Excellent
S Titanium

Great

Good Great Excellent
P

Non-alloy steel

Excellent Excellent
HRc
13252832
HB
125190250270300
P

Low alloy steel

Excellent Excellent
HRc
10293238
HB
180275300350
P

High alloy & tool steel

Excellent Excellent
HRc
1535
HB
200325
M

Stainless steel

Good Good
HRc
152310
HB
200240180
K

Grey cast iron

Good Good
HRc
1026
HB
180260
K

Nodular cast iron

Good Good
HRc
325
HB
160250
K

Malleable cast iron

Good Good
HRc
21
HB
130230
N

Aluminium. wrought

Good Good
HRc
HB
60100
N

Aluminium. cast

Good Good
HRc
HB
7590130
N

Copper. bronze. brass

Good Good
HRc
HB
11090100
N

Non-metallics

Good Good
HRc
HB
S

Heat-resistant superalloys

Good Good
HRc
HB
200280250350
S

Titanium alloys

Good Good
HRc
HB
H

Hardened steels & cast irons

Good Good
HRc
40
HB
630

Speeds & Feeds

ISO VDI 3323  Material Description Ae Ap Parameter Diameter (Ø)
1.0 1.5 2.0 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0 20.0
P 1-4 Non-Alloy Steel 0.1D 1.0D Vc 55 55 60 70 80 85 90 90 85 90 90 95 90
fz 0.002 0.005 0.006 0.009 0.019 0.024 0.03 0.042 0.047 0.047 0.047 0.048 0.047
RPM 17507 11671 9549 7427 6366 5411 4775 3581 2706 2387 2046 1890 1432
FEED 105 175 172 201 363 390 430 451 381 337 289 272 202
5 0.1D 1.0D Vc 30 35 40 45 50 50 55 55 55 55 55 60 65
fz 0.002 0.004 0.006 0.009 0.019 0.024 0.031 0.038 0.038 0.037 0.037 0.038 0.037
RPM 9549 7427 6366 4775 3979 3183 2918 2188 1751 1459 1251 1194 875
FEED 57 89 115 129 227 229 271 249 200 162 139 136 97
6-7 Low-Alloy Steel 0.1D 1.0D Vc 55 55 60 70 80 85 90 90 85 90 90 95 90
fz 0.002 0.005 0.006 0.009 0.019 0.024 0.03 0.042 0.047 0.047 0.047 0.048 0.047
RPM 17507 11671 9549 7427 6366 5411 4775 3581 2706 2387 2046 1890 1432
FEED 105 175 172 201 363 390 430 451 381 337 289 272 202
8-9 0.1D 1.0D Vc 55 55 60 70 80 85 90 90 85 90 90 95 90
fz 0.002 0.005 0.006 0.009 0.019 0.024 0.03 0.042 0.047 0.047 0.047 0.048 0.047
RPM 17507 11671 9549 7427 6366 5411 4775 3581 2706 2387 2046 1890 1432
FEED 105 175 172 201 363 390 430 451 381 337 289 272 202
10 High-Alloyed Steel, and Tool Steel 0.1D 1.0D Vc 55 55 60 70 80 85 90 90 85 90 90 95 90
fz 0.002 0.005 0.006 0.009 0.019 0.024 0.03 0.042 0.047 0.047 0.047 0.048 0.047
RPM 17507 11671 9549 7427 6366 5411 4775 3581 2706 2387 2046 1890 1432
FEED 105 175 172 201 363 390 430 451 381 337 289 272 202
11.1-11.2 0.1D 1.0D Vc 55 55 60 70 80 85 90 90 85 90 90 95 90
fz 0.002 0.005 0.006 0.009 0.019 0.024 0.03 0.042 0.047 0.047 0.047 0.048 0.047
RPM 17507 11671 9549 7427 6366 5411 4775 3581 2706 2387 2046 1890 1432
FEED 105 175 172 201 363 390 430 451 381 337 289 272 202
M 14.1 Stainless steel 0.1D 1.0D Vc 25 35 35 35 40 40 45 45 45 45 45 45 45
fz 0.002 0.004 0.006 0.009 0.018 0.024 0.03 0.042 0.045 0.045 0.044 0.048 0.048
RPM 7958 7427 5570 3714 3183 2546 2387 1790 1432 1194 1023 895 716
FEED 48 89 100 100 172 183 215 226 193 161 135 129 103
K 15-20 Grey cast iron Nodular cast iron Malleable cast iron 0.1D 1.5D Vc 60 55 60 55 60 55 55 55 60 55 55 55 55
fz 0.008 0.013 0.017 0.026 0.035 0.044 0.064 0.093 0.115 0.154 0.181 0.22 0.285
RPM 19099 11671 9549 5836 4775 3501 2918 2188 1910 1459 1251 1094 875
FEED 458 455 487 455 501 462 560 611 659 674 679 722 748
N 21~22 Aluminum-wrought alloy 0.1D 1.5D Vc 140 130 140 145 140 145 145 145 145 140 145 145 140
fz 0.006 0.01 0.016 0.021 0.031 0.037 0.048 0.064 0.08 0.098 0.111 0.129 0.167
RPM 44563 27587 22282 15385 11141 9231 7692 5769 4615 3714 3297 2885 2228
FEED 802 828 1070 969 1036 1025 1108 1108 1108 1092 1098 1116 1116
23~25 Aluminum-cast,alloyed 0.1D 1.5D Vc 140 130 140 145 140 145 145 145 145 140 145 145 140
fz 0.006 0.01 0.016 0.021 0.031 0.037 0.048 0.064 0.08 0.098 0.111 0.129 0.167
RPM 44563 27587 22282 15385 11141 9231 7692 5769 4615 3714 3297 2885 2228
FEED 802 828 1070 969 1036 1025 1108 1108 1108 1092 1098 1116 1116
26-28 Copper Alloys (Bronze / Brass) 0.1D 1.5D Vc 80 95 105 105 110 105 105 110 105 105 105 110 105
fz 0.006 0.011 0.016 0.023 0.029 0.037 0.048 0.063 0.081 0.096 0.115 0.125 0.162
RPM 25465 20160 16711 11141 8754 6685 5570 4377 3342 2785 2387 2188 1671
FEED 458 665 802 769 762 742 802 827 812 802 824 821 812
29.1 Non Metallic Materials 1.0D 1.5D Vc 80 95 105 105 110 105 105 110 105 105 105 110 105
fz 0.006 0.011 0.016 0.023 0.029 0.037 0.048 0.063 0.081 0.096 0.115 0.125 0.162
RPM 25465 20160 16711 11141 8754 6685 5570 4377 3342 2785 2387 2188 1671
FEED 458 665 802 769 762 742 802 827 812 802 824 821 812
H 40 Chilled Cast Iron 0.1D 1.0D Vc 30 35 40 45 50 50 55 55 55 55 55 60 65
fz 0.002 0.004 0.006 0.009 0.019 0.024 0.031 0.038 0.038 0.037 0.037 0.038 0.037
RPM 9549 7427 6366 4775 3979 3183 2918 2188 1751 1459 1251 1194 875
FEED 57 89 115 129 227 229 271 249 200 162 139 136 97
RPM: – rev/min
FEED: – mm/min
Vc: – m/min
Fz: – mm/tooth
EDP No. Mill Diameter ShankDia Length of Cut Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9553005 0.5 3 1.5 38 0~-0.030 h5 3 G9553006 0.6 3 1.5 38 0~-0.030 h5 3 G9553008 0.8 3 2 38 0~-0.030 h5 3 G9553010 1 3 2 38 0~-0.030 h5 3 G9553012 1.2 3 2 38 0~-0.030 h5 3 G9553015 1.5 3 2 38 0~-0.030 h5 3 G9553018 1.8 3 2 38 0~-0.030 h5 3
