(TZ933) HSS-PM, Metric Spiral Flute for Ni (TiAlN Coated)
TiAlN-Coated HSS-PM Spiral Flute Machine Tap
- SKU
- TZ933786
Key features
- HSS-PM machine tap with TiAlN coating
- R25 spiral flute geometry for blind holes
- Suitable for heat-resistant superalloys and titanium alloys
Made in South Korea
Designed for blind holes
R25 spiral flutes support chip evacuation when tapping blind holes to 2.5×D.
Built for demanding alloys
Cutting-edge rake angles and thread relief suit heat-resistant superalloys and titanium alloys.
Covers metric coarse threads
The TZ933 range covers ISO metric coarse sizes from M2 × 0.4 to M30 × 3.5.
| SKU | Size | Pitch (mm) | Thread length (mm) | Overall length (mm) | Neck length (mm) | Shank dia. (mm) | Square size (mm) | Square length (mm) | Flutes | Tapping drill dia. (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TZ933136 | M2 | 0.4 | 8.0 | 45.0 | 13.0 | 2.8 | 2.1 | 5.0 | 3 | 1.6 | 1-2 Weeks | $57.80 | ||
| TZ933176 | M2.5 | 0.45 | 9.0 | 50.0 | 15.0 | 2.8 | 2.1 | 5.0 | 3 | 2.05 | 1-2 Weeks | $50.30 | ||
| TZ933496 | M2.6 | 0.45 | 9.0 | 50.0 | 15.0 | 2.8 | 2.1 | 5.0 | 3 | 2.1 | 1-2 Weeks | $50.30 | ||
| TZ933206 | M3 | 0.5 | 6.0 | 56.0 | 18.0 | 3.5 | 2.7 | 6.0 | 3 | 2.5 | 1-2 Weeks | $43.40 | ||
| TZ933246 | M4 | 0.7 | 7.0 | 63.0 | 21.0 | 4.5 | 3.4 | 6.0 | 3 | 3.3 | 1-2 Weeks | $44.00 | ||
| TZ933286 | M5 | 0.8 | 8.0 | 70.0 | 25.0 | 6.0 | 4.9 | 8.0 | 3 | 4.2 | 1-2 Weeks | $45.60 | ||
| TZ933316 | M6 | 1 | 10.0 | 80.0 | 30.0 | 6.0 | 4.9 | 8.0 | 3 | 5.0 | 1-2 Weeks | $48.10 | ||
| TZ933366 | M8 | 1.25 | 13.0 | 90.0 | 35.0 | 8.0 | 6.2 | 9.0 | 3 | 6.8 | 1-2 Weeks | $68.40 | ||
| TZ933426 | M10 | 1.5 | 15.0 | 100.0 | 39.0 | 10.0 | 8.0 | 11.0 | 3 | 8.5 | 1-2 Weeks | $115.00 | ||
| TZ933506 | M12 | 1.75 | 18.0 | 110.0 | 44.0 | 9.0 | 7.0 | 10.0 | 3 | 10.2 | 1-2 Weeks | $104.00 | ||
| TZ933546 | M14 | 2 | 20.0 | 110.0 | 44.0 | 11.0 | 9.0 | 12.0 | 3 | 12.0 | 1-2 Weeks | $125.40 | ||
| TZ933606 | M16 | 2 | 20.0 | 110.0 | 44.0 | 12.0 | 9.0 | 12.0 | 3 | 14.0 | 1-2 Weeks | $202.90 | ||
| TZ933656 | M18 | 2.5 | 25.0 | 125.0 | 50.0 | 14.0 | 11.0 | 14.0 | 4 | 15.5 | 1-2 Weeks | $204.30 | ||
| TZ933706 | M20 | 2.5 | 25.0 | 140.0 | 54.0 | 16.0 | 12.0 | 15.0 | 4 | 17.5 | 1-2 Weeks | $228.60 | ||
| TZ933746 | M22 | 2.5 | 25.0 | 140.0 | 54.0 | 18.0 | 14.5 | 17.0 | 4 | 19.5 | 1-2 Weeks | $313.40 | ||
| TZ933786 | M24 | 3 | 30.0 | 160.0 | 60.0 | 18.0 | 14.5 | 17.0 | 4 | 21.0 | 1-2 Weeks | $313.10 | ||
| TZ933866 | M27 | 3 | 30.0 | 160.0 | 60.0 | 20.0 | 16.0 | 19.0 | 4 | 24.0 | 1-2 Weeks | $485.20 | ||
| TZ933946 | M30 | 3.5 | 35.0 | 180.0 | 70.0 | 22.0 | 18.0 | 21.0 | 4 | 26.5 | 1-2 Weeks | $647.70 |
Add (TZ933) HSS-PM, Metric Spiral Flute for Ni (TiAlN Coated) to comparison
View Comparison- Overview
- Specifications
- Reviews
YG-1 TZ933 is a TiAlN-coated HSS-PM metric spiral flute machine tap for blind holes. It produces ISO metric coarse internal threads in nickel alloys, heat-resistant superalloys and titanium alloys. R25 spiral flutes direct chips from blind holes, supporting tapping depths up to 2.5×D. Cutting-edge rake angles and thread relief suit demanding titanium and superalloy threading applications. TiAlN coating identifies this dedicated TZ933 configuration within the YG-1 Ti Ni range. Metric coarse sizes range from M2 × 0.4 to M30 × 3.5. Sizes M2 to M10 use DIN 371 shanks, while M12 to M30 use DIN 376. Three or four flutes are specified according to the selected thread size.
- HSS-PM machine tap with TiAlN coating
- R25 spiral flute geometry for blind holes
- Suitable for heat-resistant superalloys and titanium alloys
- Supports blind-hole tapping to 2.5×D
- ISO metric coarse thread sizes from M2 to M30
- DIN 371 and DIN 376 shank configurations
No specifications available.
