(G9400) K-2,Drill Mill
Code: G9400030
Made in South Korea
If you're not 100% happy with your purchase, we'll replace or refund.
| SKU | Mill Diameter (mm) | Overall length (mm) | Shank dia. (mm) | Length of cut (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|
| G9400030 | 3 | 50.0 | 4.0 | 6.0 | In stock | $72.00 | ||
| G9400040 | 4 | 50.0 | 5.0 | 8.0 | Low stock | $80.50 | ||
| G9400050 | 5 | 50.0 | 6.0 | 10.0 | 5 days | $91.50 | ||
| G9400060 | 6 | 60.0 | 8.0 | 12.0 | Low stock | $96.10 | ||
| G9400080 | 8 | 70.0 | 10.0 | 16.0 | In stock | $136.40 | ||
| G9400100 | 10 | 70.0 | 12.0 | 18.0 | Low stock | $169.40 | ||
| G9400120 | 12 | 70.0 | 12.0 | 20.0 | 5 days | $170.60 | ||
| G9400140 | 14 | 80.0 | 14.0 | 24.0 | 5 days | $27.10 | ||
| G9400160 | 16 | 80.0 | 16.0 | 26.0 | 5 days | $239.84 | ||
| G9400200 | 20 | 100.0 | 20.0 | 32.0 | 5 days | $426.92 |
Add (G9400) K-2,Drill Mill to comparison
View Comparison- Overview
- Specifications
- Operation
- Work Material
- Reviews
Product Description
The G9400 series Uncoated Carbide Solid Chamfer Drill Mill features a 45 degree chamfer angle (90 degrees inclusive) for primarily machining an inclined surface on the shoulder of a workpiece. Also suitable for bevelling, deburring, spotting and countersinking. They are supplied with a plain shank, most suitable for being clamped in an ER collet chuck. Solid carbide Chamfer Drill Mills offer longer tool life and better performance compared to HSS.Being uncoated, they are optimal for general purpose machining on a variety of materials.
Features & Benefits
- 45 degree chamfer angle (90 degree inclusive angle)
- Solid carbide substrate for longer tool life and better performance compared to HSS
- Suitable for drilling, milling, chamfering, spotting and v-grooving
- Uncoated carbide ideal for general purpose applications
Specifications
| Flutes | 2 |
| Helix Angle | 30° |
| Cutting Edge Shape |
DRILL MILL
|
| Size Min | D3.0 |
| Size Max | D20.0 |
| Length |
-
|
| Coating |
TiAlN
|
Product Data
| Workpiece Material | P M K N |
| Cutting Shape | Square |
| Helix Angle | Square 30 |
| No. Flutes | 2 |
| Operation | Die Sinking, Facing, Side Milling, Slotting, Small Part |
| Shank Type | 6535HA, Plain YG-1 Standard |
| Surface Treatment | Titanium Aluminium Nitride Coating |
| Tool Material | Carbide |
Side Milling
Small Part
Slotting
Die Sinking
Facing
Alloy Steels
Great
Good
Great
Excellent
Stainless Steels
Excellent
Good
Great
Excellent
Cast Iron
Great
Good
Great
Excellent
Aluminium
Great
Good
Great
Excellent
No VDI recommendations set for this product.
