(GM886) X-Power Pro Carbide 2Flute Corner Radius Rib Processing End Mill,

Y-Coated 2 Flute Ball Nose End Mill for Rib Processing

(GM886) X-Power Pro Carbide 2Flute Corner Radius Rib Processing End Mill,
$120.67 INC GST $109.70 EX GST
SKU
GM886005

Key features

  • Solid carbide two-flute ball nose geometry for rib processing
  • Y-Coating for the GM886 cutting tool series
  • 30° helix design for profiling and side milling
Mill Diameter (mm)
Ball Nose Radius (mm)
Length Below Shank (mm)
Loading stock…
South Korea Made in South Korea
Free standard delivery on orders over $500.
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

Rib machining geometry

Two-flute ball nose geometry supports narrow-rib machining and detailed mould and die profiles.

Useful size selection

Choose from R0.25 to R3.0 ball radii with varied lengths below shank.

Steel machining focus

The X-Power Pro range is specified for pre-hardened steels up to HRc55.

SKUMill Diameter (mm)Ball Nose Radius (mm)Length Below Shank (mm)Overall length (mm)Shank dia. (mm)FlutesLength of cut (mm)Neck dia. (mm)Stock Price Qty Add
GM8860050.5R0.252.045.04.020.70.45 Quantity unavailable $109.70
GM8869620.5R0.254.045.04.020.70.45 In stock $48.97
GM8869570.6R0.32.045.04.020.90.55 1-2 Weeks $109.70
GM8869150.6R0.34.045.04.020.90.55 1-2 Weeks $109.70
GM8869160.6R0.36.045.04.020.90.55 In stock $48.97
GM8869190.8R0.44.045.04.021.20.75 1-2 Weeks $85.40
GM8860080.8R0.46.045.04.021.20.75 In stock $34.24
GM8869211.0R0.54.045.04.021.50.95 In stock $42.06
GM8869231.0R0.55.045.04.021.50.95 1-2 Weeks $78.80
GM8860101.0R0.56.045.04.021.50.95 1-2 Weeks $78.80
GM8869021.0R0.58.045.04.021.50.95 In stock $31.60
GM8869031.0R0.510.045.04.021.50.95 1-2 Weeks $78.80
GM8869041.0R0.512.045.04.021.50.95 In stock $33.61
GM8869271.0R0.516.050.04.021.50.95 1-2 Weeks $89.60
GM8860121.2R0.68.045.04.021.81.15 In stock $37.34
GM8869301.5R0.756.045.04.022.31.45 Low stock $43.09
GM8860151.5R0.758.045.04.022.31.45 In stock $31.60
GM8869311.5R0.7510.045.04.022.31.45 1-2 Weeks $78.80
GM8869061.5R0.7512.045.04.022.31.45 In stock $33.61
GM8869402.0R1.06.045.04.023.01.95 1-2 Weeks $73.80
GM8860202.0R1.08.045.04.023.01.95 In stock $31.60
GM8869412.0R1.010.045.04.023.01.95 In stock $31.60
GM8869422.0R1.012.050.04.023.01.95 1-2 Weeks $73.80
GM8869092.0R1.016.050.04.023.01.95 In stock $37.34
GM8869102.0R1.020.055.04.023.01.95 1-2 Weeks $84.00
GM8869452.0R1.025.060.04.023.01.95 1-2 Weeks $84.00
GM8869672.0R1.030.070.04.023.01.95 In stock $38.71
GM8869473.0R1.510.050.06.024.52.85 1-2 Weeks $117.60
GM8869483.0R1.512.050.06.024.52.85 In stock $36.35
GM8860303.0R1.516.055.06.024.52.85 In stock $51.91
GM8869113.0R1.520.060.06.024.52.85 Low stock $55.72
GM8869683.0R1.525.065.06.024.52.85 In stock $47.15
GM8860404.0R2.016.060.06.026.03.85 Low stock $43.93
GM8869124.0R2.020.065.06.026.03.85 1-2 Weeks $117.60
GM8869134.0R2.025.070.06.026.03.85 1-2 Weeks $117.60
GM8869714.0R2.030.070.06.026.03.85 Low stock $69.40
GM8869724.0R2.035.080.06.026.03.85 1-2 Weeks $139.60
GM8860505.0R2.516.060.06.027.54.85 1-2 Weeks $109.50
GM8860606.0R3.020.080.06.029.05.85 1-2 Weeks $117.60
GM8869546.0R3.030.090.06.029.05.85 1-2 Weeks $126.90

Add (GM886) X-Power Pro Carbide 2Flute Corner Radius Rib Processing End Mill, to comparison

View Comparison
  • Overview
  • Reviews
Product Description

YG-1 GM886 X-Power Pro is a solid carbide, two-flute ball nose end mill for rib processing. This Y-coated plain-shank tool is designed for narrow-rib machining and detailed mould and die profiles. Its 30° helix complements the two-flute design for profiling and side milling. GM886 offers ball radii from R0.25 to R3.0, corresponding to 0.5–6.0 mm mill diameters.

Selected variants provide lengths below shank from 2 to 35 mm for varied reach requirements. The X-Power Pro range is specified for pre-hardened steels up to HRc55 in mould and die work. Select the listed radius, diameter, and reach to suit the required rib geometry.

  • Solid carbide two-flute ball nose geometry for rib processing
  • Y-Coating for the GM886 cutting tool series
  • 30° helix design for profiling and side milling
  • Ball nose radii from R0.25 to R3.0
  • Plain shank construction
  • Specified for pre-hardened steels up to HRc55
Product Data

No specifications available.
