This product is part of a promotion !
EM80 RL-E Magnetic Drill
Made in Germany
SKU: 18629
The EM80 RL-E Magnetic Drill delivers impressive performance, including a tapping capacity of up to M30, a forward-reversible drive, a morse taper 3 spindle, and solid brass guides.
- 3 Coil 20,000N Magnetic Adhesion
- Tapping capacity up to M30
- 4-Step Variable Speed Oil Bath Gearbox
- Forward-reversible drive - ideal for tapping
- Morse Taper 3 spindle
- Solid Brass Guides
| Drill Features and Specifications | |
| Core Drill Dimensions | 50.0-110.0mm |
| Cutting Depth | 50/110.omm |
| Twist Drill |
1.0-16.0mm with drill chuck up to 32.0mm with MT3 DIN |
| Counter-Boring |
10.0-55.0mm |
| Tapping |
Tapping Chucks: Up to M30 with Tapping Attachment: Up to M30 |
| Arbors |
MT3 |
| Stroke |
190mm |
| Height Adjustment |
60mm |
| 4-Speed Gearbox |
1. Step 50-110rpm 2. Step 75-175rpm 3. Step 105-245rpm 4. Step 165-385rpm |
| Power Consumption |
1,800W |
| Voltage |
230V 50/60Hz |
| Tool Force (10mm)/Magnetic Adhesion Strength |
4,000N/20,000N |
| Magnetic Base |
92×238mm, 30° adjustable right and left, 10mm front and back |
| Weight |
22.0Kg |
