DIN371/DIN376 COMBO Spiral Point Steam Homo (TB834)

DIN371/DIN376 COMBO Spiral Point Steam Homo (TB834)
$0.00 INC GST $0.00 EX GST Price available on request
SKU
TB834742
Work materials
PMKN
Tool material HSS-E
Surface treatment Steam Oxide Coating
Loading stock…
South Korea Made in South Korea
Free standard delivery on orders over $500.
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

SKUTitleThread length (mm)Overall length (mm)Neck length (mm)Shank dia. (mm)Square size (mm)Square length (mm)FlutesTapping drill dia. (mm)Stock Price Qty Add
TB834742Default Title32.0140.054.018.014.517.0419.5 1-2 Weeks -

Add DIN371/DIN376 COMBO Spiral Point Steam Homo (TB834) to comparison

View Comparison
  • Overview
  • Specifications
  • Operation
  • Work Material
  • Reviews
Product Description
  • For using multi-purpose and correct thread profiles & long tool life due to special tap geometry.
  • YG-1 company has a patent.
Product Data
Workpiece Material P M K N
Operation Blind Drilling
Surface Treatment Steam Oxide Coating
Thread Angle 60
Thread Class 2B
Thread Form B
Thread Shape UNC
Tool Material HSS-E
Tool Standard DIN 371-376
EDP No. Size TPI Thread Length Overall Length Neck Length Shank Diameter Square Size Square Length No. of Flute TB834162 #4 40 11 56 18 3.5 2.7 6 3 TB834202 #5 40 11 56 18 3.5 2.7 6 3 TB834242 #6 32 12 56 20 4 3 6 3 TB834282 #8 32 13 63 21 4.5 3.4 6 3 TB834322 #10 24 15 70 25 6 4.9 8 3 TB834362 #12 24 16 80 30 6 4.9 8 3 TB834402 1/4 20 17 80 30 7 5.5 8 3 TB834442 5/16 18 20 90 35 8 6.2 9 3 TB834482 3/8 16 22 100 39 9 7 10 3 TB834522 7/16 14 22 100 40 8 6.2 9 3 TB834562 1/2 13 25 110 44 9 7 10 3 TB834602 9/16 12 26 110 44 11 9 12 3 TB834642 5/8 11 27 110 44 12 9 12 3 TB834702 3/4 10 30 125 50 14 11 14 4 TB834742 7/8 9 32 140 54 18 14.5 17 4 TB834782 1" 8 36 160 60 20 16 19 4
Blind Drilling

Work materials

Material recommendations for this tool.

ExcellentGood

Steel

Carbon Steels
Excellent
Alloy Steels
Excellent
Structural Steels
Good
Mild & Free Machining
Excellent
High Alloyed
Good

Cast iron

Cast Iron
Good

Stainless steel

Stainless Steels
Good

Non-ferrous materials

Aluminium
Good
Copper
Excellent
Bronze
Excellent
Plastic
Good

These are broad material recommendations; specific VDI grades are not stated.

EDP No. Size TPI Thread Length Overall Length Neck Length Shank Diameter Square Size Square Length No. of Flute TB834162 #4 40 11 56 18 3.5 2.7 6 3 TB834202 #5 40 11 56 18 3.5 2.7 6 3 TB834242 #6 32 12 56 20 4 3 6 3 TB834282 #8 32 13 63 21 4.5 3.4 6 3 TB834322 #10 24 15 70 25 6 4.9 8 3 TB834362 #12 24 16 80 30 6 4.9 8 3 TB834402 1/4 20 17 80 30 7 5.5 8 3 TB834442 5/16 18 20 90 35 8 6.2 9 3 TB834482 3/8 16 22 100 39 9 7 10 3 TB834522 7/16 14 22 100 40 8 6.2 9 3 TB834562 1/2 13 25 110 44 9 7 10 3 TB834602 9/16 12 26 110 44 11 9 12 3 TB834642 5/8 11 27 110 44 12 9 12 3 TB834702 3/4 10 30 125 50 14 11 14 4 TB834742 7/8 9 32 140 54 18 14.5 17 4 TB834782 1" 8 36 160 60 20 16 19 4

Combo Tap
