(TTS37) HSS-PM, Metric Synchro tap Cold Forming Tap with Oil Grooves for General Purpose (TiN Coated
TiN HSS-PM synchro cold forming tap with oil grooves
- SKU
- TTS37206
Key features
- TiN-coated HSS-PM synchro cold forming tap
- Oil groove design with six grooves
- Forms metric 6HX internal threads
Made in South Korea
Synchro tapping focus
Built for high-speed tapping on rigid CNC machines in synchro tapping applications.
Lubrication feature
Six oil grooves are specified throughout the listed metric size range.
Metric thread range
Listed variants cover M3 x 0.5 to M12 x 1.75 internal threads.
| SKU | Size | Pitch | Thread length (mm) | Overall length (mm) | Neck length (mm) | Shank dia. (mm) | Square size (mm) | Square length (mm) | Flutes | Tapping drill dia. (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TTS37206 | M3 | 0.5 | 5.0 | 56.0 | 18.0 | 3.5 | 2.7 | 6.0 | 5 | 2.8 | 1-2 Weeks | $45.30 | ||
| TTS37246 | M4 | 0.7 | 7.0 | 63.0 | 21.0 | 4.5 | 3.4 | 6.0 | 5 | 3.7 | No stock | $45.60 | ||
| TTS37286 | M5 | 0.8 | 8.0 | 70.0 | 25.0 | 6.0 | 4.9 | 8.0 | 5 | 4.65 | Low stock | $47.80 | ||
| TTS37316 | M6 | 1 | 10.0 | 80.0 | 30.0 | 6.0 | 4.9 | 8.0 | 5 | 5.55 | 1-2 Weeks | $47.80 | ||
| TTS37366 | M8 | 1.25 | 13.0 | 90.0 | 35.0 | 8.0 | 6.2 | 9.0 | 5 | 7.4 | 1-2 Weeks | $66.00 | ||
| TTS37426 | M10 | 1.5 | 15.0 | 100.0 | 39.0 | 10.0 | 8.0 | 11.0 | 6 | 9.3 | 1-2 Weeks | $79.20 | ||
| TTS37506 | M12 | 1.75 | 18.0 | 110.0 | 44.0 | 9.0 | 7.0 | 10.0 | 6 | 11.2 | 1-2 Weeks | $110.60 |
Add (TTS37) HSS-PM, Metric Synchro tap Cold Forming Tap with Oil Grooves for General Purpose (TiN Coated to comparison
View Comparison- Overview
- Specifications
- Work Material
- Reviews
YG-1 TTS37 is a TiN-coated HSS-PM metric synchro cold forming tap with oil grooves. It forms 6HX internal metric threads for blind and through holes on rigid CNC machines. The series supports high-speed tapping and is intended for synchro tapping applications. Six oil grooves are specified for every listed metric variant. This listed range covers M3 x 0.5 through M12 x 1.75 thread sizes. DIN 371 applies from M3 to M10, while M12 uses DIN 376 dimensions. Select a synchro holder where required to help improve tool life and thread quality. TiN coating and HSS-PM construction identify this general-purpose thread forming tap.
- TiN-coated HSS-PM synchro cold forming tap
- Oil groove design with six grooves
- Forms metric 6HX internal threads
- Suitable for blind and through holes
- For high-speed tapping on rigid CNC machines
- M3 x 0.5 to M12 x 1.75 listed range
| Surface Treatment | Titanium Nitride Coating |
| Tool Material | HSS PM |
Work materials
VDI 3323 recommendations for this tool.
Steel
6 gradesNon-ferrous materials
6 gradesStainless steel
3 gradesVDI grade reference15 grades
Individual grade ratings and nominal hardness references. Base grades and decimal subgrades are listed separately.
| VDI | Work material | Recommendation | HB ref. | HRC ref. |
|---|---|---|---|---|
| 1 | PNon-alloy steel | Excellent | 125 | - |
| 2 | PNon-alloy steel | Excellent | 190 | 13 |
| 3 | PNon-alloy steel | Excellent | 250 | 25 |
| 4 | PNon-alloy steel | Excellent | 270 | 28 |
| 6 | PLow-alloy steel | Excellent | 180 | 10 |
| 7 | PLow-alloy steel | Excellent | 275 | 29 |
| 12 | MStainless steel | Excellent | 200 | 15 |
| 13 | MStainless steel | Excellent | 240 | 23 |
| 14 | MStainless steel | Excellent | 180 | 10 |
| 21 | NWrought aluminium | Excellent | 60 | - |
| 22 | NWrought aluminium | Excellent | 100 | - |
| 23 | NCast aluminium | Excellent | 75 | - |
| 24 | NCast aluminium | Excellent | 90 | - |
| 25 | NCast aluminium | Good | 130 | - |
| 28 | NCopper, bronze and brass | Excellent | 100 | - |
No grades match your search.
HB and HRC values are nominal catalogue references. Grade subdivisions can vary between catalogues.
Recommendations apply to the listed VDI grades. Unlisted grades have no stated recommendation.
