The 35°/37° helix configuration supports the GMF56 long-length milling design.
Designed for milling steels, cast iron and stainless steels.
Choose from 3 to 25 mm cutter diameters with chamfer edge preparation.
| SKU | Mill Diameter (mm) | Chamfer (mm) | Overall length (mm) | Shank dia. (mm) | Length of cut (mm) | CAD files | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|---|
| GMF56030 | 3.0 | R0.10 | 57.0 | 6.0 | 8.0 | STEPDXF | In stock | $57.64 | ||
| GMF56040 | 4.0 | R0.15 | 57.0 | 6.0 | 11.0 | STEPDXF | In stock | $57.64 | ||
| GMF56050 | 5.0 | R0.15 | 57.0 | 6.0 | 13.0 | STEPDXF | Low stock | $57.64 | ||
| GMF56060 | 6.0 | R0.20 | 57.0 | 6.0 | 13.0 | STEPDXF | In stock | $57.64 | ||
| GMF56080 | 8.0 | R0.20 | 63.0 | 8.0 | 19.0 | STEPDXF | In stock | $81.35 | ||
| GMF56100 | 10.0 | R0.30 | 72.0 | 10.0 | 22.0 | STEPDXF | In stock | $130.17 | ||
| GMF56120 | 12.0 | R0.35 | 83.0 | 12.0 | 26.0 | STEPDXF | In stock | $156.71 | ||
| GMF56140 | 14.0 | R0.40 | 83.0 | 14.0 | 26.0 | STEPDXF | 1-2 Weeks | $258.48 | ||
| GMF56160 | 16.0 | R0.40 | 92.0 | 16.0 | 32.0 | STEPDXF | Restocking | $320.24 | ||
| GMF56180 | 18.0 | R0.50 | 92.0 | 18.0 | 32.0 | STEPDXF | 1-2 Weeks | $474.81 | ||
| GMF56200 | 20.0 | R0.50 | 104.0 | 20.0 | 38.0 | STEPDXF | Low stock | $591.18 | ||
| GMF56250 | 25.0 | R0.50 | 104.0 | 25.0 | 38.0 | STEPDXF | 1-2 Weeks | $832.02 |
Add (GMF56) V7 Plus Carbide, 4Flute Multi Helix End Mill, Long length, Plain Shank to comparison
View ComparisonYG-1 V7 Plus GMF56 is a solid carbide four-flute multiple-helix long-length chamfer end mill. The 35°/37° multiple-helix design supports milling steels, cast iron and stainless steels. Each tool has a plain shank and four flutes for long-length milling applications. Chamfer edge preparation is included to suit parts requiring a chamfered cutting edge. It is a practical choice for workshops machining steel, cast iron or stainless steel components. Available cutter diameters run from 3 to 25 mm with lengths of cut from 8 to 38 mm. Overall lengths span 57 to 104 mm and chamfers range from 0.10 to 0.50 mm.
| Cutting Shape | Square |
| Length | Long |
| No. Flutes | 4 |
| Tool Material | Carbide |
VDI 3323 recommendations for this tool.
Individual grade ratings and nominal hardness references. Base grades and decimal subgrades are listed separately.
| VDI | Work material | Recommendation | HB ref. | HRC ref. |
|---|---|---|---|---|
| 1 | PNon-alloy steel | Excellent | 125 | - |
| 2 | PNon-alloy steel | Excellent | 190 | 13 |
| 3 | PNon-alloy steel | Excellent | 250 | 25 |
| 4 | PNon-alloy steel | Excellent | 270 | 28 |
| 5 | PNon-alloy steel | Excellent | 300 | 32 |
| 6 | PLow-alloy steel | Excellent | 180 | 10 |
| 7 | PLow-alloy steel | Excellent | 275 | 29 |
| 8 | PLow-alloy steel | Excellent | 300 | 32 |
| 9 | PLow-alloy steel | Excellent | 350 | 38 |
| 10 | PHigh-alloy and tool steel | Excellent | 200 | 15 |
| 11 | PHigh-alloy and tool steel | Excellent | 325 | 35 |
| 12 | MStainless steel | Excellent | 200 | 15 |
| 13 | MStainless steel | Excellent | 240 | 23 |
| 14 | MStainless steel | Excellent | 180 | 10 |
| 15 | KGrey cast iron | Excellent | 180 | 10 |
| 16 | KGrey cast iron | Excellent | 260 | 26 |
| 17 | KNodular cast iron | Excellent | 160 | 3 |
| 18 | KNodular cast iron | Excellent | 250 | 25 |
| 19 | KMalleable cast iron | Excellent | 130 | - |
| 20 | KMalleable cast iron | Excellent | 230 | 21 |
| 31 | SHeat-resistant superalloys | Good | 200 | 15 |
| 32 | SHeat-resistant superalloys | Good | 280 | 30 |
| 33 | SHeat-resistant superalloys | Good | 250 | 25 |
| 34 | SHeat-resistant superalloys | Good | 350 | 38 |
| 35 | SHeat-resistant superalloys | Good | 320 | 34 |
| 36 | STitanium alloys | Good | - | - |
| 37 | STitanium alloys | Good | - | - |
No grades match your search.
HB and HRC values are nominal catalogue references. Grade subdivisions can vary between catalogues.
Recommendations apply to the listed VDI grades. Unlisted grades have no stated recommendation.
Select the operation, workpiece material and tool diameter to calculate the recommended cutting parameters for this product.
