Six-Flute Extra-Long Flat-Shank Carbide End Mill
Buy now from our online retailers:
Select your preferred distributor:
Variable-pitch geometry is designed to reduce chatter during high-speed and trochoidal milling operations.
Extra-long proportions support deeper access while retaining a six-flute carbide cutting configuration.
Suitable for steel, stainless steel and cast iron machining in low and medium-hardness materials.
| SKU | Mill Diameter (mm) | Overall length (mm) | Shank dia. (mm) | Length of cut (mm) | CAD files | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|
| GMG15060 | 6.0 | 75.0 | 6.0 | 24.0 | STEPDXF | 1-2 Weeks | $90.50 | ||
| GMG15080 | 8.0 | 75.0 | 8.0 | 32.0 | STEPDXF | 1-2 Weeks | $132.70 | ||
| GMG15100 | 10.0 | 100.0 | 10.0 | 40.0 | STEPDXF | 1-2 Weeks | $220.40 | ||
| GMG15120 | 12.0 | 120.0 | 12.0 | 48.0 | STEPDXF | 1-2 Weeks | $274.40 | ||
| GMG15160 | 16.0 | 140.0 | 16.0 | 64.0 | STEPDXF | 1-2 Weeks | $485.00 | ||
| GMG15200 | 20.0 | 150.0 | 20.0 | 80.0 | STEPDXF | 1-2 Weeks | $953.40 | ||
| GMG15250 | 25.0 | 170.0 | 25.0 | 100.0 | STEPDXF | 1-2 Weeks | $1,425.50 |
Add (GMG15) V7 Plus Carbide, 6Flute End Mill, Extra Long length, Flat Shank to comparison
View ComparisonThe YG-1 V7 Plus GMG15 is a solid carbide six-flute extra-long end mill with a flat shank. Its Y-Coated construction and variable-pitch geometry support chatter-free high-speed and trochoidal milling. It is intended for steels, cast iron and stainless steels, including low and medium-hardness materials below 40 HRC. The 45° helix supports productive machining while the extra-long design provides extended reach. GMG15 tools suit facing, side milling, profiling and trochoidal milling where stable engagement is required. The family covers 6 to 25 mm cutting diameters, with 24 to 100 mm lengths of cut. Flat-shank variants are supplied in overall lengths from 75 to 170 mm.
| Cutting Shape | Square |
| Length | Extra Long |
| No. Flutes | 6 |
| Surface Treatment | YG-1 Y Coating |
| Tool Material | Carbide |
VDI 3323 recommendations for this tool.
Individual grade ratings and nominal hardness references. Base grades and decimal subgrades are listed separately.
| VDI | Work material | Recommendation | HB ref. | HRC ref. |
|---|---|---|---|---|
| 1 | PNon-alloy steel | Excellent | 125 | - |
| 2 | PNon-alloy steel | Excellent | 190 | 13 |
| 3 | PNon-alloy steel | Excellent | 250 | 25 |
| 4 | PNon-alloy steel | Excellent | 270 | 28 |
| 5 | PNon-alloy steel | Excellent | 300 | 32 |
| 6 | PLow-alloy steel | Excellent | 180 | 10 |
| 7 | PLow-alloy steel | Excellent | 275 | 29 |
| 8 | PLow-alloy steel | Excellent | 300 | 32 |
| 9 | PLow-alloy steel | Excellent | 350 | 38 |
| 10 | PHigh-alloy and tool steel | Excellent | 200 | 15 |
| 11 | PHigh-alloy and tool steel | Excellent | 325 | 35 |
| 12 | MStainless steel | Excellent | 200 | 15 |
| 13 | MStainless steel | Excellent | 240 | 23 |
| 14 | MStainless steel | Excellent | 180 | 10 |
| 15 | KGrey cast iron | Excellent | 180 | 10 |
| 16 | KGrey cast iron | Excellent | 260 | 26 |
| 17 | KNodular cast iron | Excellent | 160 | 3 |
| 18 | KNodular cast iron | Excellent | 250 | 25 |
| 19 | KMalleable cast iron | Excellent | 130 | - |
| 20 | KMalleable cast iron | Excellent | 230 | 21 |
| 31 | SHeat-resistant superalloys | Good | 200 | 15 |
| 32 | SHeat-resistant superalloys | Good | 280 | 30 |
| 33 | SHeat-resistant superalloys | Good | 250 | 25 |
| 34 | SHeat-resistant superalloys | Good | 350 | 38 |
| 35 | SHeat-resistant superalloys | Good | 320 | 34 |
| 36 | STitanium alloys | Good | - | - |
| 37 | STitanium alloys | Good | - | - |
No grades match your search.
HB and HRC values are nominal catalogue references. Grade subdivisions can vary between catalogues.
Recommendations apply to the listed VDI grades. Unlisted grades have no stated recommendation.
Select the operation, workpiece material and tool diameter to calculate the recommended cutting parameters for this product.
