(T1042) HSS-E (M35) Metric/Metric Fine Gun Point Tap for General Purpose (JIS Standard)

Gun Point Tap for General Purpose

YG-1 T1042 official product photograph · transparent
$22.77 INC GST $20.70 EX GST
SKU
T1042132
Work materials
PMKN
Tool material HSS-E
Surface treatment Steam Homo
Size
TPI
Loading stock…
South Korea Made in South Korea
Free standard delivery on orders over $500.
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

SKUSizeTPIThread length (mm)Overall length (mm)Neck length (mm)Shank dia. (mm)Square size (mm)Square length (mm)FlutesTapping drill dia. (mm)CAD filesStock Price Qty Add
T1042132M20.415.040.040.03.02.55.021.6STEPDXF 1-2 Weeks $20.70
T1042152M2.20.4515.042.042.03.02.55.021.75STEPDXF 1-2 Weeks $24.20
T1042192M2.30.415.042.042.03.02.55.021.9STEPDXF 1-2 Weeks $22.80
T1042172M2.50.4516.044.044.03.02.55.022.1STEPDXF 1-2 Weeks $20.20
T1042492M2.60.4516.044.044.03.02.55.022.2STEPDXF 1-2 Weeks $18.30
T1042212M30.3510.046.046.04.03.26.032.7STEPDXF 1-2 Weeks $12.10
T1042202M30.518.046.046.04.03.26.032.5STEPDXF 1-2 Weeks $8.70
T1042232M3.50.3510.048.048.04.03.26.033.2STEPDXF 1-2 Weeks $12.10
T1042222M3.50.618.048.048.04.03.26.032.9STEPDXF 1-2 Weeks $12.10
T1042252M40.515.052.052.05.04.07.033.5STEPDXF 1-2 Weeks $12.20
T1042242M40.720.052.052.05.04.07.033.3STEPDXF 1-2 Weeks $10.80
T1042272M4.50.515.055.055.05.04.07.034.0STEPDXF 1-2 Weeks $11.70
T1042262M4.50.7520.055.055.05.04.07.033.8STEPDXF 1-2 Weeks $11.70
T1042292M50.515.060.060.05.54.57.034.5STEPDXF 1-2 Weeks $12.10
T1042282M50.822.060.060.05.54.57.034.2STEPDXF 1-2 Weeks $11.10
T1042302M5.50.515.060.060.05.54.57.035.0STEPDXF 1-2 Weeks $13.30
T1042332M60.515.055.055.06.04.57.035.5STEPDXF 1-2 Weeks $12.00
T1042322M60.7520.062.062.06.04.57.035.3STEPDXF 1-2 Weeks $12.70
T1042312M6124.062.062.06.04.57.035.0STEPDXF 1-2 Weeks $11.60
T1042352M70.7520.065.065.06.25.08.036.3STEPDXF 1-2 Weeks $13.80
T1042342M7126.065.065.06.25.08.036.0STEPDXF 1-2 Weeks $13.80
T1042383M80.7526.065.065.06.25.08.037.3STEPDXF 1-2 Weeks $17.60
T1042373M8130.070.070.06.25.08.037.0STEPDXF 1-2 Weeks $17.60
T1042363M81.2530.070.070.06.25.08.036.8STEPDXF 1-2 Weeks $12.60
T1042413M90.7526.065.065.07.05.58.038.3STEPDXF 1-2 Weeks $19.60
T1042403M9130.070.070.07.05.58.038.0STEPDXF 1-2 Weeks $19.60
T1042393M91.2530.072.072.07.05.58.037.8STEPDXF 1-2 Weeks $19.60
T1042453M100.7526.065.065.07.05.58.039.3STEPDXF 1-2 Weeks $22.80
T1042443M10130.070.070.07.05.58.039.0STEPDXF 1-2 Weeks $22.80
T1042433M101.2532.075.075.07.05.58.038.8STEPDXF 1-2 Weeks $22.80
T1042423M101.532.075.075.07.05.58.038.5STEPDXF 1-2 Weeks $16.60
T1042483M110.7526.065.065.08.06.09.0310.3STEPDXF 1-2 Weeks $30.00
T1042474M11130.070.070.08.06.09.0310.0– 1-2 Weeks $30.00
T1042463M111.538.080.080.08.06.09.039.5STEPDXF 1-2 Weeks $30.00
T1042533M12130.070.070.08.56.59.0311.0STEPDXF 1-2 Weeks $31.70
T1042523M121.2538.080.080.08.56.59.0310.8STEPDXF 1-2 Weeks $24.40
T1042513M121.538.082.082.08.56.59.0310.5STEPDXF 1-2 Weeks $24.40
T1042504M121.7538.082.082.08.56.59.0310.3STEPDXF 1-2 Weeks $22.80
T1042573M14130.070.070.010.58.011.0313.0STEPDXF 1-2 Weeks $37.70
T1042563M141.2538.080.080.010.58.011.0312.8STEPDXF 1-2 Weeks $34.70
T1042553M141.542.088.088.010.58.011.0312.5STEPDXF 1-2 Weeks $37.70
T1042544M14242.088.088.010.58.011.0312.0STEPDXF 1-2 Weeks $37.70
T1042593M15130.070.070.010.58.011.0314.0STEPDXF 1-2 Weeks $48.40
T1042583M151.542.090.090.010.58.011.0313.5STEPDXF 1-2 Weeks $48.40
T1042623M16130.075.075.012.510.013.0315.0STEPDXF 1-2 Weeks $38.80
T1042613M161.545.095.095.012.510.013.0314.5STEPDXF 1-2 Weeks $38.80
T1042604M16245.095.095.012.510.013.0314.0STEPDXF 1-2 Weeks $43.80
T1042683M18130.080.080.014.011.014.0317.0STEPDXF 1-2 Weeks $51.70
T1042674M181.545.095.095.014.011.014.0316.5STEPDXF 1-2 Weeks $51.70
T1042664M18245.095.095.014.011.014.0316.0STEPDXF 1-2 Weeks $51.70
T1042654M182.548.0100.0100.014.011.014.0315.5STEPDXF 1-2 Weeks $51.70
T1042733M20130.080.080.015.012.015.0319.0STEPDXF 1-2 Weeks $59.30
T1042724M201.545.095.095.015.012.015.0318.5STEPDXF 1-2 Weeks $59.30
T1042714M20245.095.095.015.012.015.0318.0STEPDXF 1-2 Weeks $59.30
T1042704M202.550.0105.0105.015.012.015.0317.5STEPDXF 1-2 Weeks $59.30
T1042773M22130.085.085.017.013.016.0321.0STEPDXF 1-2 Weeks $83.70
T1042764M221.545.095.095.017.013.016.0320.5STEPDXF 1-2 Weeks $83.70
T1042754M22245.095.095.017.013.016.0320.0STEPDXF 1-2 Weeks $83.70
T1042744M222.555.0115.0115.017.013.016.0319.5STEPDXF 1-2 Weeks $83.70
T1042813M24130.095.095.019.015.018.0323.0STEPDXF 1-2 Weeks $116.90
T1042804M241.545.095.095.019.015.018.0322.5STEPDXF 1-2 Weeks $116.90
T1042794M24245.095.095.019.015.018.0322.0STEPDXF 1-2 Weeks $116.90
T1042784M24358.0120.0120.019.015.018.0321.0STEPDXF 1-2 Weeks $116.90
T1042834M251.545.095.095.019.015.018.0323.5STEPDXF 1-2 Weeks $122.80
T1042824M25245.095.095.019.015.018.0323.0STEPDXF 1-2 Weeks $122.80
T1042N53M26130.095.095.020.015.018.0425.0STEPDXF 1-2 Weeks $131.30
T1042854M261.545.095.095.020.015.018.0424.5STEPDXF 1-2 Weeks $131.30
T1042N44M26245.095.095.020.015.018.0424.0STEPDXF 1-2 Weeks $131.30
T1042884M271.545.095.095.020.015.018.0425.5STEPDXF 1-2 Weeks $150.50
T1042874M27245.095.095.020.015.018.0425.0STEPDXF 1-2 Weeks $150.50
T1042864M27362.0130.0130.020.015.018.0424.0STEPDXF 1-2 Weeks $150.50
T1042914M281.545.0105.0105.021.017.020.0426.5STEPDXF 1-2 Weeks $172.80
T1042904M28245.0105.0105.021.017.020.0426.0STEPDXF 1-2 Weeks $172.80
T1042982M30130.0105.0105.023.017.020.0429.0STEPDXF 1-2 Weeks $196.90
T1042974M301.545.0105.0105.023.017.020.0428.5STEPDXF 1-2 Weeks $196.90
T1042964M30245.0105.0105.023.017.020.0428.0STEPDXF 1-2 Weeks $196.90
T1042954M30365.0135.0135.023.017.020.0427.0STEPDXF 1-2 Weeks $196.90
T1042945M303.565.0135.0135.023.017.020.0426.5STEPDXF 1-2 Weeks $196.90
T1042A74M331.545.0110.0110.025.019.022.0431.5STEPDXF 1-2 Weeks $258.70
T1042A63M33245.0110.0110.025.019.022.0431.0STEPDXF 1-2 Weeks $258.70
T1042A54M33370.0145.0145.025.019.022.0430.0STEPDXF 1-2 Weeks $258.70
T1042A45M333.570.0145.0145.025.019.022.0429.5STEPDXF 1-2 Weeks $207.10
T1042B64M361.545.0110.0110.028.021.024.0434.5STEPDXF 1-2 Weeks $285.10
T1042B53M36245.0110.0110.028.021.024.0434.0STEPDXF 1-2 Weeks $285.10
T1042B44M36375.0155.0155.028.021.024.0433.0STEPDXF 1-2 Weeks $285.10
T1042B35M36475.0155.0155.028.021.024.0432.0STEPDXF 1-2 Weeks $285.10

Add (T1042) HSS-E (M35) Metric/Metric Fine Gun Point Tap for General Purpose (JIS Standard) to comparison

View Comparison
  • Overview
  • Specifications
  • Operation
  • Work Material
  • Reviews
Product Description
Product Data
Workpiece Material P M K N
Operation Through Drilling
Surface Treatment Steam Homo, Steam Oxide Coating
Thread Angle 60
Thread Class YH
Thread Form 5P
Thread Shape M, M / MF, MF
Tool Material HSS-E
EDP No. Size Pitch Thread Length Overall Length Neck Length Shank Diameter Square Size Square Length No. of Flute Tapping Drill Dia T1042A45 M33 3.5 70 145 145 25 19 22 4 29.5 T1042A54 M33 3 70 145 145 25 19 22 4 30 T1042A63 M33 2 45 110 110 25 19 22 4 31 T1042A74 M33 1.5 45 110 110 25 19 22 4 31.5 T1042B35 M36 4 75 155 155 28 21 24 4 32 T1042B44 M36 3 75 155 155 28 21 24 4 33 T1042B53 M36 2 45 110 110 28 21 24 4 34 T1042B64 M36 1.5 45 110 110 28 21 24 4 34.5 T1042N44 M26 2 45 95 95 20 15 18 4 24 T1042N53 M26 1 30 95 95 20 15 18 4 25 T1042132 M2 0.4 15 40 40 3 2.5 5 2 1.6 T1042152 M2.2 0.45 15 42 42 3 2.5 5 2 1.75 T1042172 M2.5 0.45 16 44 44 3 2.5 5 2 2.1 T1042192 M2.3 0.4 15 42 42 3 2.5 5 2 1.9 T1042202 M3 0.5 18 46 46 4 3.2 6 3 2.5 T1042212 M3 0.35 10 46 46 4 3.2 6 3 2.7 T1042222 M3.5 0.6 18 48 48 4 3.2 6 3 2.9 T1042232 M3.5 0.35 10 48 48 4 3.2 6 3 3.2 T1042242 M4 0.7 20 52 52 5 4 7 3 3.3 T1042252 M4 0.5 15 52 52 5 4 7 3 3.5 T1042262 M4.5 0.75 20 55 55 5 4 7 3 3.8 T1042272 M4.5 0.5 15 55 55 5 4 7 3 4 T1042282 M5 0.8 22 60 60 5.5 4.5 7 3 4.2 T1042292 M5 0.5 15 60 60 5.5 4.5 7 3 4.5 T1042302 M5.5 0.5 15 60 23 5.5 4.5 7 3 5 T1042312 M6 1 24 62 62 6 4.5 7 3 5 T1042322 M6 0.75 20 62 62 6 4.5 7 3 5.3 T1042332 M6 0.5 15 55 55 6 4.5 7 3 5.5 T1042342 M7 1 26 65 65 6.2 5 8 3 6 T1042352 M7 0.75 20 65 62 6.2 5 8 3 6.3 T1042363 M8 1.25 30 70 70 6.2 5 8 3 6.8 T1042373 M8 1 30 70 70 6.2 5 8 3 7 T1042383 M8 0.75 26 65 65 6.2 5 8 3 7.3 T1042393 M9 1.25 30 72 72 7 5.5 8 3 7.8 T1042403 M9 1 30 70 70 7 5.5 8 3 8 T1042413 M9 0.75 26 65 65 7 5.5 8 3 8.3 T1042423 M10 1.5 32 75 75 7 5.5 8 3 8.5 T1042433 M10 1.25 32 75 75 7 5.5 8 3 8.8 T1042443 M10 1 30 70 70 7 5.5 8 3 9 T1042453 M10 0.75 26 65 65 7 5.5 8 3 9.3 T1042463 M11 1.5 38 80 80 8 6 9 3 9.5 T1042474 M11 1 30 70 70 8 6 9 3 10 T1042483 M11 0.75 26 65 65 8 6 9 3 10.3 T1042492 M2.6 0.45 16 44 44 3 2.5 5 2 2.2 T1042504 M12 1.75 38 82 82 8.5 6.5 9 3 10.3 T1042513 M12 1.5 38 82 82 8.5 6.5 9 3 10.5 T1042523 M12 1.25 38 80 80 8.5 6.5 9 3 10.8 T1042533 M12 1 30 70 70 8.5 6.5 9 3 11 T1042544 M14 2 42 88 88 10.5 8 11 3 12 T1042553 M14 1.5 42 88 88 10.5 8 11 3 12.5 T1042563 M14 1.25 38 80 80 10.5 8 11 3 12.8 T1042573 M14 1 30 70 70 10.5 8 11 3 13 T1042583 M15 1.5 42 90 90 10.5 8 11 3 13.5 T1042593 M15 1 30 70 70 10.5 8 11 3 14 T1042604 M16 2 45 95 95 12.5 10 13 3 14 T1042613 M16 1.5 45 95 95 12.5 10 13 3 14.5 T1042623 M16 1 30 75 75 12.5 10 13 3 15 T1042654 M18 2.5 48 100 100 14 11 14 3 15.5 T1042664 M18 2 45 95 95 14 11 14 3 16 T1042674 M18 1.5 45 95 95 14 11 14 3 16.5 T1042683 M18 1 30 80 80 14 11 14 3 17 T1042704 M20 2.5 50 105 105 15 12 15 3 17.5 T1042714 M20 2 45 95 95 15 12 15 3 18 T1042724 M20 1.5 45 95 95 15 12 15 3 18.5 T1042733 M20 1 30 80 80 15 12 15 3 19 T1042744 M22 2.5 55 115 115 17 13 16 3 19.5 T1042754 M22 2 45 95 95 17 13 16 3 20 T1042764 M22 1.5 45 95 95 17 13 16 3 20.5 T1042773 M22 1 30 85 85 17 13 16 3 21 T1042784 M24 3 58 120 120 19 15 18 3 21 T1042794 M24 2 45 95 95 19 15 18 3 22 T1042804 M24 1.5 45 95 95 19 15 18 3 22.5 T1042813 M24 1 30 95 95 19 15 18 3 23 T1042824 M25 2 45 95 95 19 15 18 3 23 T1042834 M25 1.5 45 95 95 19 15 18 3 23.5 T1042854 M26 1.5 45 95 95 20 15 18 4 24.5 T1042864 M27 3 62 130 130 20 15 18 4 24 T1042874 M27 2 45 95 95 20 15 18 4 25 T1042884 M27 1.5 45 95 95 20 15 18 4 25.5 T1042904 M28 2 45 105 105 21 17 20 4 26 T1042914 M28 1.5 45 105 105 21 17 20 4 26.5 T1042945 M30 3.5 65 135 135 23 17 20 4 26.5 T1042954 M30 3 65 135 135 23 17 20 4 27 T1042964 M30 2 45 105 105 23 17 20 4 28 T1042974 M30 1.5 45 105 105 23 17 20 4 28.5 T1042982 M30 1 30 105 105 23 17 20 4 29
Through Drilling

Work materials

Material recommendations for this tool.

ExcellentGood

Steel

Carbon Steels
Good
Alloy Steels
Good
Structural Steels
Excellent
Mild & Free Machining
Excellent
Tool Steels
Good
High Alloyed
Good

Cast iron

Cast Iron
Good

Stainless steel

Stainless Steels
Good

Non-ferrous materials

Aluminium
Good
Copper
Good
Bronze
Good

These are broad material recommendations; specific VDI grades are not stated.
