N
Aluminium. wrought
HRc
HB
60100
N
Aluminium. cast
HRc
HB
7590130
N
Non-metallics
HRc
HB
(EI451) D-Power Carbide 2Flute Ball Nose End Mill, Long Length Neck for Graphite (Diamond Coated)
Code: EI451020
Made in South Korea
If you're not 100% happy with your purchase, we'll replace or refund.
| SKU | Mill Diameter (mm) | Ball Nose Radius (mm) | Overall length (mm) | Shank dia. (mm) | Length of cut (mm) | Length below shank (mm) | Neck dia. (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|---|---|
| EI451020 | 2 | R1.0 | 80.0 | 4.0 | 10.0 | 20.0 | 1.95 | Low stock | $148.60 | ||
| EI451030 | 3 | R1.5 | 80.0 | 4.0 | 15.0 | 25.0 | 2.9 | Low stock | $137.90 | ||
| EI451040 | 4 | R2.0 | 80.0 | 4.0 | 20.0 | 30.0 | 3.9 | 5 days | $137.90 | ||
| EI451050 | 5 | R2.5 | 100.0 | 6.0 | 30.0 | 50.0 | 4.9 | 5 days | $176.40 | ||
| EI451060 | 6 | R3.0 | 100.0 | 6.0 | 30.0 | 50.0 | 5.5 | 5 days | $176.40 | ||
| EI451070 | 7 | R3.5 | 100.0 | 6.0 | 30.0 | - | - | 5 days | - | ||
| EI451080 | 8 | R4.0 | 110.0 | 8.0 | 40.0 | 60.0 | 7.5 | 5 days | $224.20 | ||
| EI451090 | 9 | R4.5 | 110.0 | 8.0 | 40.0 | - | - | 5 days | - | ||
| EI451100 | 10 | R5.0 | 120.0 | 10.0 | 50.0 | 70.0 | 9.5 | Low stock | $291.60 | ||
| EI451120 | 12 | R6.0 | 130.0 | 12.0 | 55.0 | 75.0 | 11.5 | 5 days | $373.80 |
Add (EI451) D-Power Carbide 2Flute Ball Nose End Mill, Long Length Neck for Graphite (Diamond Coated) to comparison
View Comparison- Overview
- Specifications
- Specifications
- Operation
- Work Material
- Reviews
Product Description
The YG-1 EI451 series D-Power diamond coated micrograin carbide cutters has 2 flutes and a plain shank. These long length slot drills have a reduced neck and a ball nosed end for machining radii. These range in diameter from 2mm-12mm. The D-Power range is the first choice for the high performance machining of graphite. It is also suitable for machining abrasive aluminium, plastics, brass, copper, CFRP and GFRP composites.
- First choice for high performance machining of graphite with extreme wear resistance.
- Excellent performance in abrasive non-ferrous materials.
- Diamond coating has high lubricity and low coefficient of friction, preventing the tool from fast wear common in abrasive material machining.
- Long Length Ball Nosed geometry with radius tolerance ± 0.01mm
- Suitable for high accuracy machining.
- Smooth and excellent surface finish on graphite.
- Also suitable for high speed machining of Wrought Aluminium, Bakelite, Plastics, Wood, Brass and non-ferrous metals.
Product Data
| Workpiece Material | N |
| Ball Radius Tolerance | 0.01 |
| Cutting Shape | Ball Nose |
| Graphite | Excellent |
| Helix Angle | Ball Nose 30 |
| Length | Long |
| No. Flutes | 2 |
| Operation | Profiling, Side Milling, Small Part |
| Shank Type | Plain |
| Surface Treatment | Diamond Coating |
| Tool Material | Carbide |
| Flutes | 2 |
| Helix Angle | 30° |
| Cutting Edge Shape | BALL NOSE |
| Size Min | R1.0 |
| Size Max | R6.0 |
| Length |
LONG LENGTH NECK |
| Coating | Diamond |
Profiling
Side Milling
Small Part
Aluminium
Great
Good
Great
Excellent
Copper
Great
Good
Great
Excellent
CFRP
Great
Good
Great
Excellent
Non-ferrous
Great
Good
Great
Excellent
