New

THREAD MILL with Chamfer TiAlN (L4276)

TiAlN-Coated Coolant-Fed NPT Cutting
  • $427.24INC GST $388.40 EX GST
THREAD MILL with Chamfer TiAlN (L4276)
THREAD MILL with Chamfer TiAlN (L4276)
New

THREAD MILL with Chamfer TiAlN (L4276)

TiAlN-Coated Coolant-Fed NPT Cutting
  • $427.24INC GST $388.40 EX GST

Code: L4276020

P M K N S
Size
Loading stock…
Buy Local
Minimum order: $200.00
$200.00 to go
Spend $200.00 or more to enable checkout.
South Korea Made in South Korea
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

Add THREAD MILL with Chamfer TiAlN (L4276) to comparison

View Comparison
  • Overview
  • Specifications
  • Operation
  • Work Material
  • Reviews
Product Description
  • Easy to cut threads even if exotic materials like Nickel, Titanium or their alloys.
  • With Internal Coolant
  • For Internal Thread
Product Data
Workpiece Material P M K N S
Helix Angle Square 15
Operation Blind Drilling, Through Drilling
Shank Type 6535HA
Surface Treatment Titanium Aluminium Nitride Coating
Thread Angle 60
Thread Shape NPT
Tool Material Carbide
EDP No. Size TPI Thread Length Overall Length Shank Diameter No. of Flute L4276020 NPT1/16 27 8.9 64 10 3 L4276020 NPT1/16 27 8.9 64 10 3 L4276020 NPT1/16 27 8.9 64 10 3 L4276200 NPT1/8 27 8.9 70 12 4 L4276200 NPT1/8 27 8.9 70 12 4 L4276200 NPT1/8 27 8.9 70 12 4 L4276400 NPT1/4 18 13.4 81 16 4 L4276400 NPT1/4 18 13.4 81 16 4 L4276400 NPT1/4 18 13.4 81 16 4 L4276480 NPT3/8 18 13.4 81 18 4 L4276480 NPT3/8 18 13.4 81 18 4 L4276480 NPT3/8 18 13.4 81 18 4
Blind Drilling
Through Drilling
P Carbon Steels

Excellent

Good Great Excellent
P Alloy Steels

Excellent

Good Great Excellent
P Structural Steels

Excellent

Good Great Excellent
P Mild & Free Machining

Excellent

Good Great Excellent
P Tool Steels

Excellent

Good Great Excellent
P High Alloyed

Excellent

Good Great Excellent
M Stainless Steels

Great

Good Great Excellent
K Cast Iron

Excellent

Good Great Excellent
N Aluminium

Excellent

Good Great Excellent
N Bronze

Excellent

Good Great Excellent
N Copper

Excellent

Good Great Excellent
N Plastic

Excellent

Good Great Excellent
S Titanium

Great

Good Great Excellent
S Nickel

Great

Good Great Excellent
EDP No. Size TPI Thread Length Overall Length Shank Diameter No. of Flute L4276020 NPT1/16 27 8.9 64 10 3 L4276020 NPT1/16 27 8.9 64 10 3 L4276020 NPT1/16 27 8.9 64 10 3 L4276200 NPT1/8 27 8.9 70 12 4 L4276200 NPT1/8 27 8.9 70 12 4 L4276200 NPT1/8 27 8.9 70 12 4 L4276400 NPT1/4 18 13.4 81 16 4 L4276400 NPT1/4 18 13.4 81 16 4 L4276400 NPT1/4 18 13.4 81 16 4 L4276480 NPT3/8 18 13.4 81 18 4 L4276480 NPT3/8 18 13.4 81 18 4 L4276480 NPT3/8 18 13.4 81 18 4
