(GMF56) V7 Plus Carbide, 4Flute Multi Helix End Mill, Long length, Plain Shank
Long-Length 4-Flute Multiple-Helix Chamfer End MillCode: GMF56030
-
Key Features
- Solid carbide four-flute long-length chamfer end mill
- 35°/37° multiple-helix geometry
- Plain shank design
Made in South Korea
Multiple-helix geometry
The 35°/37° helix configuration supports the GMF56 long-length milling design.
Machining versatility
Designed for milling steels, cast iron and stainless steels.
Useful size range
Choose from 3 to 25 mm cutter diameters with chamfer edge preparation.
| SKU | Mill Diameter (mm) | Chamfer (mm) | Overall length (mm) | Shank dia. (mm) | Length of cut (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|
| GMF56030 | 3 | R0.10 | 57.0 | 6.0 | 8.0 | In stock | $57.64 | ||
| GMF56040 | 4 | R0.15 | 57.0 | 6.0 | 11.0 | In stock | $57.64 | ||
| GMF56050 | 5 | R0.15 | 57.0 | 6.0 | 13.0 | In stock | $57.64 | ||
| GMF56060 | 6 | R0.20 | 57.0 | 6.0 | 13.0 | In stock | $57.64 | ||
| GMF56080 | 8 | R0.20 | 63.0 | 8.0 | 19.0 | In stock | $81.35 | ||
| GMF56100 | 10 | R0.30 | 72.0 | 10.0 | 22.0 | Low stock | $130.17 | ||
| GMF56120 | 12 | R0.35 | 83.0 | 12.0 | 26.0 | Low stock | $156.71 | ||
| GMF56140 | 14 | R0.40 | 83.0 | 14.0 | 26.0 | 5 days | $258.48 | ||
| GMF56160 | 16 | R0.40 | 92.0 | 16.0 | 32.0 | Low stock | $320.24 | ||
| GMF56180 | 18 | R0.50 | 92.0 | 18.0 | 32.0 | 5 days | $474.81 | ||
| GMF56200 | 20 | R0.50 | 104.0 | 20.0 | 38.0 | Low stock | $591.18 | ||
| GMF56250 | 25 | R0.50 | 104.0 | 25.0 | 38.0 | 5 days | $832.02 |
Add (GMF56) V7 Plus Carbide, 4Flute Multi Helix End Mill, Long length, Plain Shank to comparison
View Comparison- Overview
- Specifications
- Speeds & Feeds
- Reviews
YG-1 V7 Plus GMF56 is a solid carbide four-flute multiple-helix long-length chamfer end mill. The 35°/37° multiple-helix design supports milling steels, cast iron and stainless steels. Each tool has a plain shank and four flutes for long-length milling applications. Chamfer edge preparation is included to suit parts requiring a chamfered cutting edge. It is a practical choice for workshops machining steel, cast iron or stainless steel components. Available cutter diameters run from 3 to 25 mm with lengths of cut from 8 to 38 mm. Overall lengths span 57 to 104 mm and chamfers range from 0.10 to 0.50 mm.
- Solid carbide four-flute long-length chamfer end mill
- 35°/37° multiple-helix geometry
- Plain shank design
- Suitable for steels cast iron and stainless steels
- Cutter diameters from 3 to 25 mm
- Chamfers from 0.10 to 0.50 mm
