(GMG19) V7 Plus Carbide, 4Flute Corner Radius End Mill, Extra Long length, Flat Shank

(GMG19) V7 Plus Carbide, 4Flute Corner Radius End Mill, Extra Long length, Flat Shank
$120.01 INC GST $109.10 EX GST
SKU
GMG19060
Work materials
PMKS
Tool material Carbide
Surface treatment YG-1 Y Coating
Mill Diameter (mm)
Corner Radius (mm)
Loading stock…
South Korea Made in South Korea
Free standard delivery on orders over $500.
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

SKUMill Diameter (mm)Corner Radius (mm)Overall length (mm)Shank dia. (mm)Length of cut (mm)Stock Price Qty Add
GMG190606.0R0.575.06.024.0 1-2 Weeks $109.10
GMG1910010.0R0.5100.010.040.0 1-2 Weeks $257.60
GMG1912012.0R0.5120.012.048.0 1-2 Weeks $320.40
GMG1916016.0R1.0140.016.064.0 1-2 Weeks $573.70

Add (GMG19) V7 Plus Carbide, 4Flute Corner Radius End Mill, Extra Long length, Flat Shank to comparison

View Comparison
  • Overview
  • Specifications
  • Operation
  • Work Material
  • Speeds & Feeds
  • Reviews
Application
Product Description
The V7 Plus TRP range from YG-1 are designed for hyper metal removal rates in deep slots or profiling up to 2xD. The GMG17/19 corner radius series comes with a weldon (flat) shank and a revolutionary 45° 6 flute design for phenomenal performance and outstanding surface finish. These milling cutters are also ideal for trochoidal milling applications and offer exceptional results in silent machining of steel, stainless steel and heat resistant super alloys such as inconel & cast iron. For the best results, use in a hydraulic chuck or high-performance tool holder with excellent clamping torque.
  • TRP range for the fastest metal removal rates, even in deep slots or profiling up to 2xD
  • Revolutionary 6 flute design for phenomenal performance and outstanding surface finish
  • Ideal for high speed trochoidal milling and super finishing applications
  • Multiple helix geometries and unequal flute spacing enable higher feed rates and larger cut depths with no vibration
  • Corner radius geometry with weldon (flat) shank
  • Y1200 coated with premium ultrafine micrograin carbide
  • High heat resistance of Y1200 coating ensures exceptional tool life in stainless steel, titanium and HRSA machining
  • Made by global market leader YG-1

Download Brochure

Specifications

Flutes 6
Helix Angle 45°
Cutting Edge Shape Corner Radius
Shank Flat
Coating Y-Coating



Product Data
Workpiece Material P M K S H
Cutting Shape Corner Radius
Hardened Steels(HRc40~45) Great
Helix Angle Square 45
Length Extra Long
No. Flutes 6
Operation Corner, Facing, Helical-Interpol, Side Milling, Small Part, Trochoidal
Shank Type Flat
Surface Treatment YG-1 Y Coating
Tool Material Carbide
EDP No. Radius (R) Mill Diameter (D1) ShankDia (D2) Length of Cut (l1) Overall Length (L2) Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute GMG19060 R0.50 6 6 24 75 0~-0.02 h5 6 GMG19060 R0.50 6 6 24 75 0~-0.030 h5 6 GMG19080 R0.50 8 8 32 75 0~-0.02 h5 6 GMG19080 R0.50 8 8 32 75 0~-0.030 h5 6 GMG19100 R0.50 10 10 40 100 0~-0.02 h5 6 GMG19100 R0.50 10 10 40 100 0~-0.030 h5 6 GMG19120 R0.50 12 12 48 120 0~-0.02 h6 6 GMG19120 R0.50 12 12 48 120 0~-0.030 h6 6 GMG19160 R1.0 16 16 64 140 0~-0.030 h6 6 GMG19200 R1.0 20 20 80 150 0~-0.030 h6 6 GMG19250 R1.0 25 25 100 170 0~-0.030 h6 6 GMG19901 R1.0 6 6 24 75 0~-0.02 h5 6 GMG19901 R1.0 6 6 24 75 0~-0.030 h5 6 GMG19902 R1.0 8 8 32 75 0~-0.02 h5 6 GMG19902 R1.0 8 8 32 75 0~-0.030 h5 6 GMG19903 R2.0 8 8 32 75 0~-0.02 h5 6 GMG19903 R2.0 8 8 32 75 0~-0.030 h5 6 GMG19904 R1.0 10 10 40 100 0~-0.02 h5 6 GMG19904 R1.0 10 10 40 100 0~-0.030 h5 6 GMG19905 R1.5 10 10 40 100 0~-0.02 h5 6 GMG19905 R1.5 10 10 40 100 0~-0.030 h5 6 GMG19906 R2.0 10 10 40 100 0~-0.02 h5 6 GMG19906 R2.0 10 10 40 100 0~-0.030 h5 6 GMG19907 R1.0 12 12 48 120 0~-0.02 h6 6 GMG19907 R1.0 12 12 48 120 0~-0.030 h6 6 GMG19908 R1.5 12 12 48 120 0~-0.02 h6 6 GMG19908 R1.5 12 12 48 120 0~-0.030 h6 6 GMG19909 R2.0 12 12 48 120 0~-0.02 h6 6 GMG19909 R2.0 12 12 48 120 0~-0.030 h6 6 GMG19910 R3.0 12 12 48 120 0~-0.02 h6 6 GMG19910 R3.0 12 12 48 120 0~-0.030 h6 6 GMG19911 R1.5 16 16 64 140 0~-0.030 h6 6 GMG19912 R2.0 16 16 64 140 0~-0.030 h6 6 GMG19913 R3.0 16 16 64 140 0~-0.030 h6 6 GMG19914 R1.5 20 20 80 150 0~-0.030 h6 6 GMG19915 R2.0 20 20 80 150 0~-0.030 h6 6 GMG19916 R3.0 20 20 80 150 0~-0.030 h6 6 GMG19917 R4.0 20 20 80 150 0~-0.030 h6 6 GMG19918 R5.0 20 20 80 150 0~-0.030 h6 6 GMG19919 R1.5 25 25 100 170 0~-0.030 h6 6 GMG19920 R2.0 25 25 100 170 0~-0.030 h6 6 GMG19921 R3.0 25 25 100 170 0~-0.030 h6 6 GMG19922 R4.0 25 25 100 170 0~-0.030 h6 6 GMG19923 R5.0 25 25 100 170 0~-0.030 h6 6
Side Milling
Small Part
Facing
Corner
Helical Interpol
Trochoidal

Work materials

VDI 3323 recommendations for this tool.

ExcellentGood

Steel

11 grades
Non-alloy steel
ExcellentVDI 1–5
Low-alloy steel
ExcellentVDI 6–9
High-alloy and tool steel
ExcellentVDI 10–11

Cast iron

6 grades
Grey cast iron
ExcellentVDI 15–16
Nodular cast iron
ExcellentVDI 17–18
Malleable cast iron
ExcellentVDI 19–20

Stainless steel

3 grades
Stainless steel
ExcellentVDI 12–14

Superalloys & titanium

7 grades
Heat-resistant superalloys
GoodVDI 31–35
Titanium alloys
GoodVDI 36–37
VDI grade reference27 grades

Individual grade ratings and nominal hardness references. Base grades and decimal subgrades are listed separately.

Recommended VDI grades and nominal hardness references
VDIWork materialRecommendationHB ref.HRC ref.
1PNon-alloy steelExcellent125-
2PNon-alloy steelExcellent19013
3PNon-alloy steelExcellent25025
4PNon-alloy steelExcellent27028
5PNon-alloy steelExcellent30032
6PLow-alloy steelExcellent18010
7PLow-alloy steelExcellent27529
8PLow-alloy steelExcellent30032
9PLow-alloy steelExcellent35038
10PHigh-alloy and tool steelExcellent20015
11PHigh-alloy and tool steelExcellent32535
12MStainless steelExcellent20015
13MStainless steelExcellent24023
14MStainless steelExcellent18010
15KGrey cast ironExcellent18010
16KGrey cast ironExcellent26026
17KNodular cast ironExcellent1603
18KNodular cast ironExcellent25025
19KMalleable cast ironExcellent130-
20KMalleable cast ironExcellent23021
31SHeat-resistant superalloysGood20015
32SHeat-resistant superalloysGood28030
33SHeat-resistant superalloysGood25025
34SHeat-resistant superalloysGood35038
35SHeat-resistant superalloysGood32034
36STitanium alloysGood--
37STitanium alloysGood--

HB and HRC values are nominal catalogue references. Grade subdivisions can vary between catalogues.

Recommendations apply to the listed VDI grades. Unlisted grades have no stated recommendation.

Cutting Speeds and Feeds

Select the operation, workpiece material and tool diameter to calculate the recommended cutting parameters for this product.

Machining calculator

Cutting speeds and feeds for (GMG19) V7 Plus Carbide, 4Flute Corner Radius End Mill, Extra Long length, Flat Shank

Choose the machining conditions below, then calculate the recommended spindle speed and feed rate.

Recommended parameters

Parameter Value Unit
Spindle speed – rev/min
Feed rate – mm/min
Cutting speed (Vc) – m/min
Feed per tooth (fz) – mm/tooth

Choose your options and calculate the recommended parameters.

EDP No. Radius (R) Mill Diameter (D1) ShankDia (D2) Length of Cut (l1) Overall Length (L2) Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute GMG19060 R0.50 6 6 24 75 0~-0.02 h5 6 GMG19060 R0.50 6 6 24 75 0~-0.030 h5 6 GMG19080 R0.50 8 8 32 75 0~-0.02 h5 6 GMG19080 R0.50 8 8 32 75 0~-0.030 h5 6 GMG19100 R0.50 10 10 40 100 0~-0.02 h5 6 GMG19100 R0.50 10 10 40 100 0~-0.030 h5 6 GMG19120 R0.50 12 12 48 120 0~-0.02 h6 6 GMG19120 R0.50 12 12 48 120 0~-0.030 h6 6 GMG19160 R1.0 16 16 64 140 0~-0.030 h6 6 GMG19200 R1.0 20 20 80 150 0~-0.030 h6 6 GMG19250 R1.0 25 25 100 170 0~-0.030 h6 6 GMG19901 R1.0 6 6 24 75 0~-0.02 h5 6 GMG19901 R1.0 6 6 24 75 0~-0.030 h5 6 GMG19902 R1.0 8 8 32 75 0~-0.02 h5 6 GMG19902 R1.0 8 8 32 75 0~-0.030 h5 6 GMG19903 R2.0 8 8 32 75 0~-0.02 h5 6 GMG19903 R2.0 8 8 32 75 0~-0.030 h5 6 GMG19904 R1.0 10 10 40 100 0~-0.02 h5 6 GMG19904 R1.0 10 10 40 100 0~-0.030 h5 6 GMG19905 R1.5 10 10 40 100 0~-0.02 h5 6 GMG19905 R1.5 10 10 40 100 0~-0.030 h5 6 GMG19906 R2.0 10 10 40 100 0~-0.02 h5 6 GMG19906 R2.0 10 10 40 100 0~-0.030 h5 6 GMG19907 R1.0 12 12 48 120 0~-0.02 h6 6 GMG19907 R1.0 12 12 48 120 0~-0.030 h6 6 GMG19908 R1.5 12 12 48 120 0~-0.02 h6 6 GMG19908 R1.5 12 12 48 120 0~-0.030 h6 6 GMG19909 R2.0 12 12 48 120 0~-0.02 h6 6 GMG19909 R2.0 12 12 48 120 0~-0.030 h6 6 GMG19910 R3.0 12 12 48 120 0~-0.02 h6 6 GMG19910 R3.0 12 12 48 120 0~-0.030 h6 6 GMG19911 R1.5 16 16 64 140 0~-0.030 h6 6 GMG19912 R2.0 16 16 64 140 0~-0.030 h6 6 GMG19913 R3.0 16 16 64 140 0~-0.030 h6 6 GMG19914 R1.5 20 20 80 150 0~-0.030 h6 6 GMG19915 R2.0 20 20 80 150 0~-0.030 h6 6 GMG19916 R3.0 20 20 80 150 0~-0.030 h6 6 GMG19917 R4.0 20 20 80 150 0~-0.030 h6 6 GMG19918 R5.0 20 20 80 150 0~-0.030 h6 6 GMG19919 R1.5 25 25 100 170 0~-0.030 h6 6 GMG19920 R2.0 25 25 100 170 0~-0.030 h6 6 GMG19921 R3.0 25 25 100 170 0~-0.030 h6 6 GMG19922 R4.0 25 25 100 170 0~-0.030 h6 6 GMG19923 R5.0 25 25 100 170 0~-0.030 h6 6
