(T0993) Carbide, Metric Straight Flute Tap
Carbide straight flute taps for cast iron
- SKU
- T0993206
Key features
- Carbide machine taps with bright surface treatment
- Straight flute geometry for blind and through holes
- DIN 2197 C chamfer lead
Made in South Korea
Carbide hardness
Higher hardness than HSS supports longer tool life in suitable machining applications
Cast iron application
Designed for cast iron or similar work materials, with suitability for high-silicon aluminium
Practical metric range
Covers ISO metric coarse threads from M3 × 0.5 through M20 × 2.5
| SKU | Size | Pitch | Thread length (mm) | Overall length (mm) | Neck length (mm) | Shank dia. (mm) | Square size (mm) | Square length (mm) | Flutes | Tapping drill dia. (mm) | Stock | Price | Qty | Add |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| T0993206 | M3 | 0.5 | 11.0 | 56.0 | 18.0 | 3.5 | 2.7 | 6.0 | 3 | 2.5 | 1-2 Weeks | $52.50 | ||
| T0993226 | M3.5 | 0.6 | 12.0 | 56.0 | 20.0 | 4.0 | 3.0 | 6.0 | 3 | 2.9 | 1-2 Weeks | $57.80 | ||
| T0993246 | M4 | 0.7 | 13.0 | 63.0 | 21.0 | 4.5 | 3.4 | 6.0 | 3 | 3.3 | 1-2 Weeks | $57.80 | ||
| T0993286 | M5 | 0.8 | 15.0 | 70.0 | 25.0 | 6.0 | 4.9 | 8.0 | 4 | 4.2 | 1-2 Weeks | $52.50 | ||
| T0993316 | M6 | 1 | 17.0 | 80.0 | 30.0 | 6.0 | 4.9 | 8.0 | 4 | 5.0 | 1-2 Weeks | $60.50 | ||
| T0993366 | M8 | 1.25 | 20.0 | 90.0 | 35.0 | 8.0 | 6.2 | 9.0 | 4 | 6.8 | 1-2 Weeks | $64.70 | ||
| T0993426 | M10 | 1.5 | 22.0 | 100.0 | 39.0 | 10.0 | 8.0 | 11.0 | 4 | 8.5 | 1-2 Weeks | $136.40 | ||
| T0993506 | M12 | 1.75 | 24.0 | 110.0 | 44.0 | 9.0 | 7.0 | 10.0 | 4 | 10.2 | 1-2 Weeks | $330.80 | ||
| T0993546 | M14 | 2 | 26.0 | 110.0 | 44.0 | 11.0 | 9.0 | 12.0 | 4 | 12.0 | 1-2 Weeks | $297.40 | ||
| T0993606 | M16 | 2 | 27.0 | 110.0 | 44.0 | 12.0 | 9.0 | 12.0 | 4 | 14.0 | 1-2 Weeks | $320.30 | ||
| T0993656 | M18 | 2.5 | 30.0 | 125.0 | 50.0 | 14.0 | 11.0 | 14.0 | 4 | 15.5 | 1-2 Weeks | $371.00 | ||
| T0993706 | M20 | 2.5 | 32.0 | 140.0 | 54.0 | 16.0 | 12.0 | 15.0 | 4 | 17.5 | 1-2 Weeks | $534.70 |
Add (T0993) Carbide, Metric Straight Flute Tap to comparison
View Comparison- Overview
- Specifications
- Reviews
YG-1 T0993 carbide metric straight flute taps are bright-finish machine taps for ISO metric coarse threading in cast iron. The straight flute design and DIN 2197 C chamfer lead suit machine tapping in blind and through holes. Its carbide construction offers higher hardness than HSS taps, supporting longer tool life in suitable applications. The series is suitable for cast iron and high-silicon aluminium machining applications.
It handles hole depths up to 2.0×D and includes DIN 371 sizes through M10, with DIN 376 larger sizes. The M3 × 0.5 to M20 × 2.5 range covers common metric coarse-thread tapping requirements. A bright surface treatment completes the design for practical production tapping.
- Carbide machine taps with bright surface treatment
- Straight flute geometry for blind and through holes
- DIN 2197 C chamfer lead
- ISO metric coarse threads to DIN 13
- Suitable for cast iron and high-silicon aluminium
- M3 × 0.5 to M20 × 2.5 size range
No specifications available.
