(G9A68) K-2 Carbide, 2Flute End Mill, Short Length

TiAlN-coated solid carbide slotting end mill

(G9A68) K-2 Carbide, 2Flute End Mill, Short Length
$26.84 INC GST $24.40 EX GST
SKU
G9A68010

Key features

  • TiAlN-coated solid carbide construction
  • Two-flute design for slotting
  • 30° helix geometry
Mill Diameter (mm)
Loading stock…
South Korea Made in South Korea
Free standard delivery on orders over $500.
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

Purpose-built for slotting

The two-flute geometry is specified for slotting applications.

Prepared for dry milling

TiAlN coating supports dry milling applications at high temperatures.

Useful short-length range

Sizes span 1 to 20 mm diameters with plain shanks.

SKUMill Diameter (mm)Overall length (mm)Shank dia. (mm)Length of cut (mm)Stock Price Qty Add
G9A68010139.03.03.0 1-2 Weeks $24.40
G9A680151.539.03.05.0 In stock $20.30
G9A68020239.03.07.0 In stock $20.30
G9A680252.539.03.07.0 1-2 Weeks $20.30
G9A68030339.03.09.0 In stock $20.30
G9A68040451.04.014.0 Low stock $24.90
G9A68050551.05.016.0 1-2 Weeks $27.60
G9A68060664.06.019.0 Low stock $35.60
G9A68080864.08.021.0 1-2 Weeks $51.20
G9A681001070.010.022.0 1-2 Weeks $68.90
G9A681201276.012.025.0 1-2 Weeks $91.70
G9A681601689.016.032.0 1-2 Weeks $192.00
G9A6820020102.020.038.0 1-2 Weeks $315.60

Add (G9A68) K-2 Carbide, 2Flute End Mill, Short Length to comparison

View Comparison
  • Overview
  • Specifications
  • Speeds & Feeds
  • Reviews
Application
Product Description

YG-1 G9A68 K-2 Carbide 2 Flute Short Length End Mill is a TiAlN-coated solid carbide slotting tool. It combines a 30° helix with two flutes for dry milling at high temperatures. The square cutting geometry supports slotting applications requiring a short-length end mill.

Plain-shank variants cover milling diameters from 1 to 20 mm for varied machining requirements. Length of cut ranges from 3 to 38 mm, with overall lengths from 39 to 102 mm. Diameters below 3 mm use 3 mm shanks, while larger tools have matching diameter shanks. The G9A68 series offers a short-length format for dry slot milling applications.

  • TiAlN-coated solid carbide construction
  • Two-flute design for slotting
  • 30° helix geometry
  • Square cutting end
  • Suitable for dry milling at high temperatures
  • 1 to 20 mm milling diameter range
Product Data

No specifications available.

EDP No. Mill Diameter ShankDia Length of Cut Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9A68010 1 3 3 39 0~-0.030 h5 2 G9A68015 1.5 3 5 39 0~-0.030 h5 2 G9A68020 2 3 7 39 0~-0.030 h5 2 G9A68025 2.5 3 7 39 0~-0.030 h5 2 G9A68030 3 3 9 39 0~-0.030 h5 2 G9A68040 4 4 14 51 0~-0.030 h5 2 G9A68050 5 5 16 51 0~-0.030 h5 2 G9A68060 6 6 19 64 0~-0.030 h5 2 G9A68080 8 8 21 64 0~-0.030 h5 2 G9A68100 10 10 22 70 0~-0.030 h5 2 G9A68120 12 12 25 76 0~-0.030 h5 2 G9A68160 16 16 32 89 0~-0.030 h5 2 G9A68200 20 20 38 102 0~-0.030 h5 2

Cutting Speeds and Feeds

Select the operation, workpiece material and tool diameter to calculate the recommended cutting parameters for this product.

Machining calculator

Cutting speeds and feeds for (G9A68) K-2 Carbide, 2Flute End Mill, Short Length

Choose the machining conditions below, then calculate the recommended spindle speed and feed rate.

Recommended parameters

Parameter Value Unit
Spindle speed – rev/min
Feed rate – mm/min
Cutting speed (Vc) – m/min
Feed per tooth (Fz) – mm/tooth

Choose your options and calculate the recommended parameters.

EDP No. Mill Diameter ShankDia Length of Cut Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9A68010 1 3 3 39 0~-0.030 h5 2 G9A68015 1.5 3 5 39 0~-0.030 h5 2 G9A68020 2 3 7 39 0~-0.030 h5 2 G9A68025 2.5 3 7 39 0~-0.030 h5 2 G9A68030 3 3 9 39 0~-0.030 h5 2 G9A68040 4 4 14 51 0~-0.030 h5 2 G9A68050 5 5 16 51 0~-0.030 h5 2 G9A68060 6 6 19 64 0~-0.030 h5 2 G9A68080 8 8 21 64 0~-0.030 h5 2 G9A68100 10 10 22 70 0~-0.030 h5 2 G9A68120 12 12 25 76 0~-0.030 h5 2 G9A68160 16 16 32 89 0~-0.030 h5 2 G9A68200 20 20 38 102 0~-0.030 h5 2
