(G9A69) K-2 Carbide, 2Flute End Mill, Short Length

Four-Flute TiAlN-Coated Short-Length Carbide End Mill

(G9A69) K-2 Carbide, 2Flute End Mill, Short Length
$22.33 INC GST $20.30 EX GST
SKU
G9A69010

Key features

  • Carbide square end mills with a TiAlN coating
  • Four-flute geometry supports improved workpiece finishes
  • Suitable for dry milling applications at high temperatures
Mill Diameter (mm)
Loading stock…
South Korea Made in South Korea
Free standard delivery on orders over $500.
!If you're not 100% happy with your purchase, we'll replace or refund.
Buy Online

Buy now from our online retailers:

Select your preferred distributor:

Dry milling capability

Suitable for dry milling applications at high temperatures.

Improved surface finish

Four flutes are designed to support better workpiece finishes.

Useful size coverage

Mill diameters from 1.0 to 20.0 mm cover common short-length milling needs.

SKUMill Diameter (mm)Overall length (mm)Shank dia. (mm)Length of cut (mm)Stock Price Qty Add
G9A69010139.03.03.0 1-2 Weeks $20.30
G9A690151.539.03.05.0 In stock $20.30
G9A69020239.03.07.0 1-2 Weeks $20.30
G9A690252.539.03.07.0 1-2 Weeks $24.40
G9A69030339.03.010.0 Low stock $20.30
G9A69040451.04.014.0 Low stock $24.90
G9A69050551.05.016.0 1-2 Weeks $27.60
G9A69060664.06.019.0 Low stock $35.60
G9A69080864.08.021.0 Low stock $48.60
G9A691001070.010.022.0 Low stock $73.40
G9A691201276.012.025.0 1-2 Weeks $91.70
G9A691601689.016.032.0 1-2 Weeks $160.20
G9A6920020102.020.038.0 1-2 Weeks $315.60

Add (G9A69) K-2 Carbide, 2Flute End Mill, Short Length to comparison

View Comparison
  • Overview
  • Specifications
  • Speeds & Feeds
  • Reviews
Application
Product Description

YG-1 G9A69 K-2 Carbide four-flute short-length end mills combine TiAlN coating with square cutting geometry. They are designed for dry milling at high temperatures and support improved workpiece finishes. Carbide construction and a plain shank suit practical machining applications requiring compact cutter lengths. The range covers 1.0 to 20.0 mm mill diameters for common milling requirements. Matching shank diameters span 3 to 20 mm throughout the available range. Length of cut increases from 3 to 38 mm between the smallest and largest sizes. Overall lengths span 39 to 102 mm, supporting selection for short-length milling operations. This high-performance K-2 series provides a focused solution for dry milling applications.

  • Carbide square end mills with a TiAlN coating
  • Four-flute geometry supports improved workpiece finishes
  • Suitable for dry milling applications at high temperatures
  • Short-length plain-shank design
  • Mill diameter range from 1.0 to 20.0 mm
  • Length of cut range from 3 to 38 mm
Product Data

No specifications available.

EDP No. Mill Diameter ShankDia Length of Cut Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9A69010 1 3 3 39 0~-0.030 h5 4 G9A69015 1.5 3 5 39 0~-0.030 h5 4 G9A69020 2 3 7 39 0~-0.030 h5 4 G9A69025 2.5 3 7 39 0~-0.030 h5 4 G9A69030 3 3 10 39 0~-0.030 h5 4 G9A69040 4 4 14 51 0~-0.030 h5 4 G9A69050 5 5 16 51 0~-0.030 h5 4 G9A69060 6 6 19 64 0~-0.030 h5 4 G9A69080 8 8 21 64 0~-0.030 h5 4 G9A69100 10 10 22 70 0~-0.030 h5 4 G9A69120 12 12 25 76 0~-0.030 h5 4 G9A69160 16 16 32 89 0~-0.030 h5 4 G9A69200 20 20 38 102 0~-0.030 h5 4

Cutting Speeds and Feeds

Select the operation, workpiece material and tool diameter to calculate the recommended cutting parameters for this product.

Machining calculator

Cutting speeds and feeds for (G9A69) K-2 Carbide, 2Flute End Mill, Short Length

Choose the machining conditions below, then calculate the recommended spindle speed and feed rate.

Recommended parameters

Parameter Value Unit
Spindle speed – rev/min
Feed rate – mm/min
Cutting speed (Vc) – m/min
Feed per tooth (Fz) – mm/tooth

Choose your options and calculate the recommended parameters.

EDP No. Mill Diameter ShankDia Length of Cut Overall Length Mill Dia. Tolerance Shank Dia. Tolerance No. of Flute G9A69010 1 3 3 39 0~-0.030 h5 4 G9A69015 1.5 3 5 39 0~-0.030 h5 4 G9A69020 2 3 7 39 0~-0.030 h5 4 G9A69025 2.5 3 7 39 0~-0.030 h5 4 G9A69030 3 3 10 39 0~-0.030 h5 4 G9A69040 4 4 14 51 0~-0.030 h5 4 G9A69050 5 5 16 51 0~-0.030 h5 4 G9A69060 6 6 19 64 0~-0.030 h5 4 G9A69080 8 8 21 64 0~-0.030 h5 4 G9A69100 10 10 22 70 0~-0.030 h5 4 G9A69120 12 12 25 76 0~-0.030 h5 4 G9A69160 16 16 32 89 0~-0.030 h5 4 G9A69200 20 20 38 102 0~-0.030 h5 4
